Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
NEWTOP
-
Weight:
-
10
-
Rated power/speed:
-
3000/3600
-
Starting system:
-
Recoil starting
-
Engine Type:
-
160F single cylinder,4-stroke,horizontal,air cooled
-
Cylinder NO.-bore*stroke (mm):
-
68*45mm
-
Rated power:
-
3.7kW
-
Compression ratio:
-
8.5:1
-
Max. torque:
-
10.2N.m
-
Fuel tank capacity:
-
3.6L
-
Gross weight:
-
18kg
Quick Details
-
Displacement:
-
163cc, 163cc
-
Emission Standard:
-
Euro 2
-
Power:
-
5HP
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
NEWTOP
-
Weight:
-
10
-
Rated power/speed:
-
3000/3600
-
Starting system:
-
Recoil starting
-
Engine Type:
-
160F single cylinder,4-stroke,horizontal,air cooled
-
Cylinder NO.-bore*stroke (mm):
-
68*45mm
-
Rated power:
-
3.7kW
-
Compression ratio:
-
8.5:1
-
Max. torque:
-
10.2N.m
-
Fuel tank capacity:
-
3.6L
-
Gross weight:
-
18kg
|
Model NO.
|
NTE160
|
|
Power (hp)
|
5.5hp
|
|
Displacement (cc/ml)
|
163cc
|
|
Starting system
|
Recoil starting
|
|
Engine Type
|
160F single cylinder,4-stroke,horizontal,air cooled gasoline engine
|
|
Cylinder NO.-bore×stroke (mm)
|
68×45mm
|
|
Rated power ((kW/(r/min))
|
3.7kW/3600r/min
|
|
Compression ratio
|
8.5:1
|
|
Max. torque (N.m/rpm)
|
10.2N.m/2500rpm
|
|
Fuel tank capacity (L)
|
3.6L
|
|
Oil tank capacity (L)
|
0.6L
|
|
Cooling system
|
Air cooled
|
|
Combustion system
|
Direct injection
|
|
Net weight
|
16kg (35.3 lbs.)
|
|
Gross weight
|
18kg (39.7 lbs.)
|
The NEWTOP NTE160 is a 163cc (9.9 cu-in) single-cylinder inclined by 25° air-cooled 4-stroke internal combustion small gasoline engine with horizontal shaft manufactured by Honda Motor Company for general-purpose applications, such as commercial lawn and garden equipment, tillers and cultivators, generators, construction and industrial equipment, agricultural equipment and water pumps.
