Strong and Efficient Power Transmission System The renowned brand engine equipped features strong power, ultra-low emission, and
higher fuel efficiency. The static hydraulic drive technology adopted features stable drive and high efficiency and reliability.
The fully-sealed sprocket case and high strength chains feature automatic lubrication and maintenance-free.
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
China
-
Dimension(Long * Breadth * High):
-
3270*1807*1970mm
-
Machine Weight:
-
3140 kg
-
Bucket capacity:
-
0.35cbm
-
Operating Weight:
-
2950 kg
-
Rated Operation Capacity:
-
795 kg
-
Bucket Breakout Force:
-
20.8 kN
-
Dump Clearance - Full Height:
-
2220 mm
-
Dump Reach - Full Height:
-
540 mm
-
Overall Length with Standard Bucket:
-
3362 mm
-
Overall Width with Standard Bucket:
-
1630 mm
-
Overall Height to top of Cab:
-
1940 mm
Quick Details
-
Engine Brand:
-
Top Brand
-
Power:
-
35.7KW
-
Brand Name:
-
Tewrex
-
Place of Origin:
-
China
-
Dimension(Long * Breadth * High):
-
3270*1807*1970mm
-
Machine Weight:
-
3140 kg
-
Bucket capacity:
-
0.35cbm
-
Operating Weight:
-
2950 kg
-
Rated Operation Capacity:
-
795 kg
-
Bucket Breakout Force:
-
20.8 kN
-
Dump Clearance - Full Height:
-
2220 mm
-
Dump Reach - Full Height:
-
540 mm
-
Overall Length with Standard Bucket:
-
3362 mm
-
Overall Width with Standard Bucket:
-
1630 mm
-
Overall Height to top of Cab:
-
1940 mm
Product Description
Mini Skid Steer Underground Mine Loader 1t Skid Steer Loader XC740K
Skid Steer Loader With Track 7.5t Skid Steer Loader XC740K
Compact structure, low turning radius, and strong site adaptability.
The quick-change coupling equipped can change attachments rapidly in the construction site.
The bucket can automatically maintain level status during lifting to prevent scattering of material and improve working
efficiency.
Incomparable Multi-functionality
The international interchangeable quick-change coupling enables the change of tens of attachments, including sweeper, planer, breaking hammer, and ditcher, rapidly and conveniently.
Safe and Comfortable Operating Environment
The ROPS&FOPS cab and the seat belt, bumper, fire extinguisher, and safety hammer equipped guarantee the personal safety of the operator. The cab features large space, adjustable seats, and comfortable operations.
The standard double-accelerator control model can use the pedal accelerator or work at preset constant power to save the operation labor.
Convenient Maintenance
The cab can be tilted backward for a large angle to make the repair and maintenance portions more accessible.
The rear hood and upper hood can be opened conveniently and all units and pipelines are easily accessible to save the repair and maintenance labor and time.
|
Description
|
Unit
|
|
Parameter value
|
|
|
Rated load
|
kg
|
|
750
|
|
|
Tipping load
|
kg
|
|
1500
|
|
|
Operating weight
|
kg
|
|
3140
|
|
|
Maximum breakout force
|
kN
|
|
18
|
|
|
Engine
|
Manufacturer
|
|
Xinchai
|
|
|
|
Model
|
|
4D27G31
|
|
|
|
Rated power
|
Hp/kw
|
49.3/36.8
|
|
|
|
Rated speed
|
rpm
|
2500
|
|
|
|
Cooling mode
|
|
Water-cooling
|
|
|
Performance parameter
|
Operation mode
|
Mechanical & multi-function electronic control
|
|
|
|
|
Tire standard
|
|
10-16.5
|
|
|
|
Maximum speed
|
Km/h
|
14
|
|
|
Hydraulic system
|
Hydraulic flow rate
|
L/min
|
62.5
|
|
|
|
Optional large flow
|
|
/
|
|
|
|
Hydraulic pressure
|
bar
|
200
|
|
|
Maximum operating height
|
mm
|
|
3878
|
|
|
Bucket hinge pin height
|
mm
|
|
3057
|
|
|
Cabin top height
|
mm
|
|
1960
|
|
|
Maximum horizontal height of bucket bottom
|
mm
|
|
2851
|
|
|
Length without bucket
|
mm
|
|
2533
|
|
|
Length with bucket
|
mm
|
|
3310
|
|
|
Toppling angle
|
°
|
|
40
|
|
|
Maximum unloading height
|
mm
|
|
2375
|
|
|
Ground-bucket angle
|
°
|
|
30
|
|
|
Rotating angle of bucket at highest point
|
°
|
|
83
|
|
|
Unloading distance
|
mm
|
|
575
|
|
|
Wheel base
|
mm
|
|
1027
|
|
|
Departure angle
|
°
|
|
25
|
|
