Quick Details
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
SYNMEC
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1950x500x1200mm
-
Weight:
-
380 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
Maize milling machine
-
Application:
-
Maize milling and peeling
-
Make flour capacity:
-
450kg/h
-
Make grits capacity:
-
500kg/h
-
Power:
-
11.5kw
-
Dimension:
-
2350x1500x1400
-
Peeling rate:
-
Over 98%
-
Mainly make grits:
-
50-55% grits, 10-15% flour
-
Mainly make flour:
-
60% flour, 5-10% grits
Quick Details
-
Type:
-
T series maize milling machine
-
Use:
-
maize milling and peeling
-
Production Capacity:
-
Over 98%
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
SYNMEC
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1950x500x1200mm
-
Weight:
-
380 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
Maize milling machine
-
Application:
-
Maize milling and peeling
-
Make flour capacity:
-
450kg/h
-
Make grits capacity:
-
500kg/h
-
Power:
-
11.5kw
-
Dimension:
-
2350x1500x1400
-
Peeling rate:
-
Over 98%
-
Mainly make grits:
-
50-55% grits, 10-15% flour
-
Mainly make flour:
-
60% flour, 5-10% grits
PRODUCT DISPLAY
INTRODUCTION
This machine mainly has three functions: corn peeling, corn grits (slag making) flour milling, and finished product grading. It can clean, peel, remove germs, remove roots, remove black navel, crush, take grits, and grind corn at one time. , Grading, polishing, and other processes, and finally divided into three kinds of finished products, medium grits, small grits (corn dregs), and corn flour. The size of grits (slag) can be adjusted by the slag-making handle, and the distance between the two slag-making disks, so as to control the size of grits (slag), the smallest is the grinding surface. The peeled corn kernels with the built-in high-efficiency winnowing dust removal fan will pass through the built-in fan duct through the machine to collect the micro-skins and impurities in the corn kernels
TECHNICAL
When the corn enters the peeling chamber from the hopper, it travels toward the exit under the rotation of the propelling ribs. In the peeling chamber, due to the gradual reduction of the working chamber volume and the influence of the mechanical resistance, the density of the corn kernels increases accordingly. With the enhancement of squeezing and friction in the machine, the rollers are constantly turning and advancing, and the friction and peeling between the machine parts become more obvious so that the corn kernels are removed. The decontaminated corn kernel enters the crushing system. Under the crushing and traction of the traction clutch crushing device, it travels in the crushing process and enters the grading system. Through automatic separation, corn grits, corn grits or corn flour can be obtained. After that, the dust is cleaned and removed by the air-net dust removal system, and the product obtained is bright in color and excellent in taste. In addition, the general corn peeling and the grits-making machine are also suitable for crushing crops such as rice, wheat, and sorghum.
PRODUCT PARAMETERS
|
Model
|
T1
|
T3
|
|
Make flour capacity
|
200kg/h
|
450kg/h
|
|
Make grits capacity
|
250-300kg/h
|
500kg/h
|
|
Power
|
7.5kw
|
11.5kw
|
|
Dimension
|
1950x500x1200mm
|
2350x1500x1400
|
|
Peeling rate
|
Over 98%
|
Over 98%
|
|
Mainly make grits
|
50-55% grits, 10-15% flour
|
50-55% grits, 10-15% flour
|
|
Mainly make flour
|
60% flour, 5-10% grits
|
60% flour, 5-10% grits
|
RELATED PRODUCTS
COMPANY PROFILE
Business since 2002, based on Huaixi industry park, Shijiazhuang City, China. During over 20 years manage, we become the woridwide
sucoessful manufacturer for grain cleaning & seed processing machinery, and the biggest one is China, has 11 hectare land with
advanoed processing equipment such as laser cutter. CNC lathe, etc. In year 12004, we start international trading. following 5
years we have rapid develop on that, so at year 2010 we buit one international brand of grain cleaning & seed processing
machinery, also funded an independent corporate entity 'SYNMEC International trading Ltd. that for provide better trading service
for our oversea customer. Until now, we have sold our machines to more than 160 countries.
PACKING & SHIPPING
COMMON PROBLEM
About Machine
1. Can one set of machine process many kinds of seeds?
Yes, you just need to buy extra screens.
2. What is the purity after processed by your machine?
If you buy one whole processing line, the purity can be 99.9% at least
3. Can you give me a solution according to my warehouse size and my special requirement?
Of course, we can.
4.Can the color be customized?
In normal case. the color is white. which is powder coated. But we also accept the customized color.
5. What is the machine warranty period?
One year after the machine arrives your seaport.
About Shipping
1. What is the package of machines?
The machine will be packed by plastic films and fixed in container or plywood case.
2. Will the machine be damaged during transport?
It will not, the machines will be fixed tightly in the container by belts fasteners, strong iron wire and steel wedge
3. Is any port of China available?
Yes.
4. Can you deliver the machine to my warehouse?
Yes, we can do door to door.
5. How long does the cargo to delivery to my address?
It takes about 15-45 workdays to arrive your address by sea
