Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
HR
-
Voltage:
-
380V 50Hz
-
Dimension(L*W*H):
-
3800*3300*1500mm
-
Weight:
-
3000kg
-
PLC Brand:
-
HR
-
Product name:
-
Drum Pulper
-
Model:
-
HR300 Drum Pulper
-
Drum Diameter:
-
3000
-
Capacity (T/D):
-
200-300
-
A type Motor Power:
-
250
-
B type Motor Power:
-
315
-
Application:
-
for paper pulp making
-
Name:
-
high quality drum pulper
-
Color:
-
Blue
-
Certification:
-
CE/ISO9001
Quick Details
-
Type:
-
Pulping Equipment
-
Production Capacity:
-
200 m/min
-
Max. workable width:
-
350mm
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
HR
-
Voltage:
-
380V 50Hz
-
Dimension(L*W*H):
-
3800*3300*1500mm
-
Weight:
-
3000kg
-
PLC Brand:
-
HR
-
Product name:
-
Drum Pulper
-
Model:
-
HR300 Drum Pulper
-
Drum Diameter:
-
3000
-
Capacity (T/D):
-
200-300
-
A type Motor Power:
-
250
-
B type Motor Power:
-
315
-
Application:
-
for paper pulp making
-
Name:
-
high quality drum pulper
-
Color:
-
Blue
-
Certification:
-
CE/ISO9001
Paper mill machinery pulping line waste paper recycling equipment drum pulper
Drum pulper belongs to Pulping System of paper machinery and is a more advanced Pulping System.
Drum pulper is a product which incorporates pulping and screening function and is particularly suitable for pulping the unsorted waste paper raw materials. For expanding the recovery and utilization the secondary fiber, reducing the environmental pollution, saving the energy, reaching the localization of papermaking equipment and saving the foreign exchange, the product has a greater economic and social benefits. Drum pulper is used for disintegrating continuously and coarse screening under a high concentration of waste paper raw materials (14%-22%).
Technical parameter
| Product name | Drum Pulper | |||||||||
| Model | AT250 | AT275 | AT300 | AT325 | AT350 | AT375 | AT400 | AT425 | ||
| Drum Diameter | ∅2500 | ∅2750 | ∅3000 | ∅3250 | ∅3500 | ∅3750 | ∅4000 | ∅4250 | ||
| Capacity (T/D) | 70-120 | 140-200 | 200-300 | 300-400 | 400-550 | 550-720 | 750-1000 | 1000-1400 | ||
| A type Motor Power | 110 | 160 | 250 | 315 | 500 | 630 | 800 | 1000 | ||
| B type Motor Power | 132 | 200 | 315 | 400 | 630 | 800 | 1000 | 1250 | ||
