Quick Details
-
Model Number:
-
OP-PS-003
-
Input Voltage Range:
-
AC100-240V 50/60Hz
-
Output Voltage:
-
12V DC
-
Output Current:
-
2A MAX
-
DC Jack (plug):
-
5.5mm*2.5mm
-
Wall Plug Type:
-
EU US UK AU optional
-
Color:
-
Black
-
Warranty:
-
2 Years
Quick Details
-
Output Type:
-
DC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
OP-PS-003
-
Input Voltage Range:
-
AC100-240V 50/60Hz
-
Output Voltage:
-
12V DC
-
Output Current:
-
2A MAX
-
DC Jack (plug):
-
5.5mm*2.5mm
-
Wall Plug Type:
-
EU US UK AU optional
-
Color:
-
Black
-
Warranty:
-
2 Years
With real CE RoHS certificate.
Please contact us which input plug you need,thanks.
| Input | Input voltage | AC 100~240V |
| Variation Frequency | 50~60Hz | |
| Input frequence | 50~60Hz | |
| Output | Output voltage | 12Volt DC |
| Output current | 2Amps | |
| Output power | 24W | |
| Application | LED lights,CD/DVD,MP3/MP4,Digital camera,Comunication Terminals Etc | |
Input Voltage: 100-240V AC
Input Frequency: 50/60 Hz
Output: DC12V 2A
Color: Black
Connect :5.5*2.5mm(Also available for 5.5*2.1mm)
Input voltage: 90-264VAC, 47/63Hz
Input current: 0.2A (maximum), 100/240V AC
Input Plug: EU US UK AU South Korea South Africa Plugs
Surge current: at 100V AC, 30A maximum / at 240V AC, 60A maximum
Leakage current: 0.25mA maximum
No load power consumption: 0.1W maximum
Output efficiency: 24W maximum
Over-voltage protection: 120% minimum
Over-current protection: 120% minimum
Short-circuit protection: automatic recovery
Output voltage range: ±5%
Ripple & Noise:1% of Output Voltage
