Quick Details
-
Brand Name:
-
tongda
-
Year:
-
2024
-
Voltage:
-
Customized to customer needs
-
Dimension(L*W*H):
-
10.6*4.5*6.5m
-
Hollow part volume:
-
3000L
-
Screw L/D Ratio:
-
32
-
Screw diameter (mm):
-
150 mm
-
Screw Heating Power(kW):
-
200 kW
-
Extruder Motor Power(kW):
-
60 kW
-
Mold Platen Size(Width)(mm):
-
2100 mm
-
Mold Platen Size(Height)(mm):
-
2000 mm
-
Air Pressure(MPa):
-
0.8 MPa
-
Air Comsumption(m³/min):
-
5 m³/min
-
Die Head Heating Power(kW):
-
46 kW
-
Accumulator Capacity(L):
-
70 L
-
Power (kW):
-
390
-
Weight (T):
-
65
-
Rotary Cylinder Brand:
-
FESTO
-
Station:
-
Single
-
Suitable bottle:
-
1000-3000L
-
Key words:
-
Automatic Extrusion Blow Moulding Machine
-
Packing:
-
Wooden
-
Use:
-
Hollow Moulding
-
Parison Control:
-
MOOG
-
Max. Size of Mold:
-
2100*2000
-
Hydraulic valve:
-
Yuken
-
Water consumption:
-
500L/min
Quick Details
-
Clamping Force (kN):
-
2000
-
Output (kg/h):
-
550 kg/h
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
tongda
-
Year:
-
2024
-
Voltage:
-
Customized to customer needs
-
Dimension(L*W*H):
-
10.6*4.5*6.5m
-
Hollow part volume:
-
3000L
-
Screw L/D Ratio:
-
32
-
Screw diameter (mm):
-
150 mm
-
Screw Heating Power(kW):
-
200 kW
-
Extruder Motor Power(kW):
-
60 kW
-
Mold Platen Size(Width)(mm):
-
2100 mm
-
Mold Platen Size(Height)(mm):
-
2000 mm
-
Air Pressure(MPa):
-
0.8 MPa
-
Air Comsumption(m³/min):
-
5 m³/min
-
Die Head Heating Power(kW):
-
46 kW
-
Accumulator Capacity(L):
-
70 L
-
Power (kW):
-
390
-
Weight (T):
-
65
-
Rotary Cylinder Brand:
-
FESTO
-
Station:
-
Single
-
Suitable bottle:
-
1000-3000L
-
Key words:
-
Automatic Extrusion Blow Moulding Machine
-
Packing:
-
Wooden
-
Use:
-
Hollow Moulding
-
Parison Control:
-
MOOG
-
Max. Size of Mold:
-
2100*2000
-
Hydraulic valve:
-
Yuken
-
Water consumption:
-
500L/min
Product Description
HT-3000L
This machine is specialized in making 1000-3000L single or double ring drum & open-top drum.This is single layer and equipped with servo motor.
The main parts of this machine are designed and manufactured by ourself. We do the independent R&D and inspection. If you have other special requirements, we can provide customized services for you.
|
MODEL
|
Units
|
HT-3000L
|
Remarks: If you have other special requirements,we can provide customized services for you.
|
|
Max. Product volume
|
L
|
3000
|
|
|
Output of HDPE
|
kg/h
|
500
|
|
|
Clamping force
|
kn
|
2000
|
|
|
Screw diametre
|
mm
|
150
|
|
|
Screw heating power
|
kw
|
70
|
|
|
Blow pressure
|
mpa
|
0.8
|
|
|
Size of machine
|
m
|
10.6*4.5*6.5
|
|
Product Details
Our Advantages
Arrange engineer to customer's factory
We supply the after-service online 24 hours
