- Product Details
- {{item.text}}
Quick Details
-
Fork Length:
-
920 mm
-
Fork Width:
-
100 mm
-
Overall Dimensions:
-
285*1070*2040 mm
-
Weight (KG):
-
3050 kg
-
Rated capacity(Kg):
-
1500
-
Load centre(mm):
-
500
-
Max.lifting height(mm):
-
3000
-
Free lifting height(mm):
-
105
-
Fork size(mm):
-
920*100*35
-
Mast tilt angle(deg):
-
6/12
-
Min.turning radius(mm):
-
1900
-
Max.traveling speed(km/h):
-
14
-
Max.lifting speed(mm/s):
-
260/420
-
Battery:
-
48/450
Quick Details
-
Min. Lifting Height:
-
105mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Fujian, China
-
Fork Length:
-
920 mm
-
Fork Width:
-
100 mm
-
Overall Dimensions:
-
285*1070*2040 mm
-
Weight (KG):
-
3050 kg
-
Rated capacity(Kg):
-
1500
-
Load centre(mm):
-
500
-
Max.lifting height(mm):
-
3000
-
Free lifting height(mm):
-
105
-
Fork size(mm):
-
920*100*35
-
Mast tilt angle(deg):
-
6/12
-
Min.turning radius(mm):
-
1900
-
Max.traveling speed(km/h):
-
14
-
Max.lifting speed(mm/s):
-
260/420
-
Battery:
-
48/450
Contact Way
Alune Xie —— Sales Manager
Mobile/Wechat/WhatsApp: +86 193-1332-9653
Email: alune@richmchn.com
Email: alune@richmchn.com
Products Description
1.5 Ton Mini Electric Forklift LG15B
Lower pollution
1.High efficiency hydraulic system decreases the fuel consumption.
2.This lift truck is equipped with high performance engine to meet EU EC and USA EPA new regulations.
Ergonomics Improved
1.Right located control lever effectively reduces driver’s arm tiredness.
2.The operator’s legroom is twice to other series with optimized construction.
3.Small diameter steering wheel reduces driver’s left shoulder’s fatigue and makes driving comfortable.
4.Suspension seat with handrail and seat belt ensure the operator’s safety and comfort.
5.The dynamic braking system decreases the braking force sharply.
Reliability Improved
1.The high strength special-shaped overhead guard is designed to ensure the safety.
2.Applying the park brake system safety protection device, avoid the hidden danger caused by faulty operation.
3.Safety wire harness, Reliability and good Maintainability.
Details Images
Product Paramenters
|
Model
|
|
LG15B
|
|
|
Power type
|
|
Battery
|
|
|
Rated capacity(Kg)
|
|
1600
|
|
|
J Load centre(mm)
|
|
500
|
|
|
h1 STD Max.lifting height(mm)
|
|
3000
|
|
|
h3 Free lifting height(mm)
|
|
105
|
|
|
L5*W*T Fork size(mm)
|
|
920×100×35
|
|
|
Mast tilt angle(deg)
|
|
6/12
|
|
|
L3 Front overhang(mm)
|
|
410
|
|
|
R1 Min.turning radius(mm)
|
|
1900
|
|
|
Min.width for pallets 1,000×1,200 crossways (L×W)(mm)
|
|
3510
|
|
|
Min.width for pallets 800×1,200 lengthways (L×W)(mm)
|
|
3710
|
|
|
Max.traveling speed(km/h)
|
|
14
|
|
|
Max.lifting speed(mm/s)（load/unload）
|
|
260/420
|
|
|
Max.gradient(load/unload)(%)
|
|
12/15
|
|
|
STD Dead weight(kg)
|
|
3050
|
|
|
S/P Tread（front/rear）(mm)
|
|
890/920
|
|
|
L2 Axle distance(mm)
|
|
1370
|
|
|
Min.ground clearance, m1 Frame(mm)
|
|
130
|
|
|
Tire
|
Front
|
6.5-10-10PR
|
|
|
|
Rear
|
5.00-8-10PR
|
|
|
Motor
|
Travel(AC)(kW)
|
7.5
|
|
|
|
Lift(AC)(kW)
|
10
|
|
|
Battery(V/Ah)
|
|
48/450
|
|
|
Working pressure(Mpa)
|
|
14.5
|
|
