Quick Details
-
Brand Name:
-
Firstrate
-
Model Number:
-
FST200-202
-
Output:
-
Analog SENSOR
-
Theory:
-
Hall Sensor
-
Material:
-
Aluminum Alloy
-
Certificate:
-
CE RoHS
-
Color:
-
black
-
Application:
-
Wide Range
-
Range:
-
0~360°
-
Signal:
-
4~20mA, 0~5V, 0~10V, RS485
-
Supply voltage:
-
15~30VDC
-
Product name:
-
Wind direction Sensor
Quick Details
-
Warranty:
-
1YEAR
-
Type:
-
Wind direction Sensor
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Firstrate
-
Model Number:
-
FST200-202
-
Output:
-
Analog SENSOR
-
Theory:
-
Hall Sensor
-
Material:
-
Aluminum Alloy
-
Certificate:
-
CE RoHS
-
Color:
-
black
-
Application:
-
Wide Range
-
Range:
-
0~360°
-
Signal:
-
4~20mA, 0~5V, 0~10V, RS485
-
Supply voltage:
-
15~30VDC
-
Product name:
-
Wind direction Sensor
Firstrate FST200-202 CE and Rohs Wind direction Sensor for Solar Tracker
♦
Focus on sensor production for more than 50 years;
♦
Factory Outlet, Low price;
♦
12 months free repaire warranty;
♦
Firstrate products have past CE, ROHS, ISO9001 etc.
| Product Introduction | |
|
FST200-202 Analog Output 0 5V 4 20mA Hall Effect Wind Vane Sensor Wind Direction Sensor is mechanical rotate sensor, cup turns round once be blown. Digital circuits capable of strong RFI & EMI resistance and automatic temperature compensation are installed inside the sensor, it outputs voltage and current signals by electromagnetic induction, the value and horizontal wind speed are linear relation.
Sensor external parts all are made of alloy material and finish by surface powder coating, featured with water proof, corrosion resisting. Inside and turning position have sealing rings with nice sealing function, stop water, salt fog and dust getting in.
|
| Product Features | |
|
♦ Strong RFI & EMI resistance and automatic temperature compensation
♦ High sensibility, high precision, high frequency response and permanent stability ♦ Excellent resistance against impact, overload, shock and erosion ♦ Small and exquisite, easy to take, simple to install ♦ Alloy material, reasonable structure and nice outlook |
|
|
Application |
|
|
♦ Working aloft testing and control
♦ Engineering machine testing and control ♦ Weather station and environment protection testing and control ♦ Port and wharf environment testing and control ♦ Other industrial automation about wind speed and direction testing and control |
| Technical Index | |
| Testing range | 0~360º |
| Start wind speed | ≤0.8m/s |
| Resolution | 22.5 º |
| Accuracy | ±3 º |
| Working Environment | Temperature: -20°C~+85°C Humidity≤95%RH |
| Output | 0-5VDC 4-20mA |
| Resistance for current output | 250Ω |
| Working Voltage | 12~30VDC (common 24VDC) |
| Limit wind speed | Max: 70m/s 30min |
| Electrical connection | M12 |
| Environmental Protection | IP65 |
