70uf 450V 50/60Hz capacitor cbb60 en60252
70uf 450V 50/60Hz capacitor cbb60 en60252
70uf 450V 50/60Hz capacitor cbb60 en60252
70uf 450V 50/60Hz capacitor cbb60 en60252
70uf 450V 50/60Hz capacitor cbb60 en60252
70uf 450V 50/60Hz capacitor cbb60 en60252
70uf 450V 50/60Hz capacitor cbb60 en60252
70uf 450V 50/60Hz capacitor cbb60 en60252

70uf 450V 50/60Hz capacitor cbb60 en60252

FOB Reference Price: Get Latest Price
≥500 Pieces
US $0.22
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Rated Voltage:
450V
Operating Temperature:
25/70/21
Capacitance:
2-100uf
color:
white
cannning material:
plastic
port:
wires
Internal material:
metallized film
Operating frequency:
50/60Hz
Voltage:
450Vac
packaging:
carton
Approvals:
CQC,UL,TUV,CE
origin:
Taizhou city, zhejiang province
Certificate:
CQC

Quick Details

Place of Origin:
Zhejiang, China
Brand Name:
DingFeng
Model Number:
cbb60
Rated Voltage:
450V
Operating Temperature:
25/70/21
Capacitance:
2-100uf
color:
white
cannning material:
plastic
port:
wires
Internal material:
metallized film
Operating frequency:
50/60Hz
Voltage:
450Vac
packaging:
carton
Approvals:
CQC,UL,TUV,CE
origin:
Taizhou city, zhejiang province
Certificate:
CQC
Company Introduction
Product Description

70uf 450V 50/60Hz capacitor cbb60 en60252

material :plastic shell,plastic lid for sealing or resin for sealing.

characteristic :Small volume,light weight,low loss,excellent self-healing performance.

others :Copper soldering terminal,plastic coated copper wire and CP wire are available.

Application :it is widely used as the start-up and running capacitor.That is specially for micro water pump.cleaning machine. washing machine and single-phase household electrical appliances etc

function :it help motors start and run and can continuously operate under rated conditions.

Dimension

70uf 450V 50/60Hz capacitor cbb60 en60252

Parameter

70uf 450V 50/60Hz capacitor cbb60 en60252

Capacitor range
1-100uf
Capacitor tolarance
±5%,±10%
Rated alterate Voltage
250V,370V,400V,450V
Rated frequency
50/60Hz
Operating temperature
40/85/21
Insulation resistance
T-T≥3000MΩ.uf(20℃.100VDC)
T-T≥2000MΩ.uf(20℃.100VDC)
Dissipation factor
Tanδ≤0.002(100Hz,20℃)
Approvals
UL,TUV,CE,CQC,ROHS.
Endurance voltage
Between the electrodes:2.0Un2s
Between the electrode and the shell:2000VAC2s
Flow Diagram
Packing&Delivery
FAQ

70uf 450V 50/60Hz capacitor cbb60 en60252

1.Q:Are you a factory or a trading company?
A:capacitor Manufactory.

2.Q: How about your quality of capacitors?
A:Producats through the industry's top customers, a number of national customer verificatiom,stable and reliable quality.

3. Q: What are your payment terms?
A:30% deposit by T/T in advance,pay 70% balance when the products are finished.

4. Q: How about the packing of this model?
A: Carton packing or as your requirement.

5. Q: About the customers response?
A: They always become our regular customers.And become good friend.

6. Q: What is your delivery time?
A:It depends on your order.Normally 20-30days for standard.

7. Q: How about the shipping time?
A: Usually it will take 4-10days for Express,7-15days for Air,25-55days for Sea,it also depends on the destination area.

8. Q: How do you guarantee your quality?
A: we have TUV RoHS CE and CQC certificates.And we ues a lot of time to test the product.

70uf 450V 50/60Hz capacitor cbb60 en60252
