- Product Details
- {{item.text}}
Quick Details
-
Marketing Type:
-
New Product 2024
-
motor:
-
230V/50HZ
-
power:
-
2000w
-
protection degree:
-
ip54
-
max splitting force:
-
5T
-
diameter:
-
50-250mm
-
length:
-
520mm
-
hydraulic oil capacity:
-
3.0L
-
packing size:
-
985*300*470mm
-
N.W/G.W:
-
57.5/55.2kg
Quick Details
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
985*300*470mm
-
Weight:
-
57.5 KG
-
Marketing Type:
-
New Product 2024
-
motor:
-
230V/50HZ
-
power:
-
2000w
-
protection degree:
-
ip54
-
max splitting force:
-
5T
-
diameter:
-
50-250mm
-
length:
-
520mm
-
hydraulic oil capacity:
-
3.0L
-
packing size:
-
985*300*470mm
-
N.W/G.W:
-
57.5/55.2kg
Product Description
Specification
|
motor
|
230V/50HZ
|
|
power
|
2000w
|
|
protection degree
|
Ip54
|
|
max splitting force
|
5T
|
|
diameter
|
50-250mm
|
|
Wood length max
|
520mm
|
|
hydraulic oil capacity
|
3.0L
|
|
packing size
|
985*300*470mm
|
|
N.W/G.W
|
57.5/55.2kg
|
Different Models:
|
Item
|
Motor
|
Power(W)
|
Max. Splitting force
|
Log Capacity
Diameter
|
Log Capacity
Length
|
Hydraulic oil capacity
|
Protection degree
|
|
HY4T-370
|
230v-50Hz
|
2000W
|
4 Ton
|
50-250mm
|
370mm
|
1.8L
|
IP 54
|
|
HY5T-520-I
|
230v-50Hz
|
2000W
|
5 Ton
|
50-250mm
|
520mm
|
3.0L
|
IP 54
|
|
HY5T-520-II
|
230v-50Hz
|
2000W
|
5 Ton
|
50-250mm
|
520mm
|
3.0L
|
IP 54
|
|
HY5T-520-III
|
230v-50Hz
|
2000W
|
5 Ton
|
50-250mm
|
520mm
|
3.0L
|
IP 54
|
|
HY5T-520-IV
|
230v-50Hz
|
2000W
|
5 Ton
|
50-250mm
|
520mm
|
3.0L
|
IP 54
|
|
HY5T-520-V
|
230v-50Hz
|
2000W
|
5 Ton
|
50-250mm
|
520mm
|
3.0L
|
IP 54
|
|
HY6T-520-I
|
230v-50Hz
|
2000W
|
6 Ton
|
50-250mm
|
520mm
|
3.0L
|
IP 54
|
|
HY6T-520-II
|
230v-50Hz
|
2000W
|
6 Ton
|
50-250mm
|
520mm
|
3.0L
|
IP 54
|
|
HY6T-520-III
|
230v-50Hz
|
2000W
|
6 Ton
|
50-250mm
|
520mm
|
3.0L
|
IP 54
|
|
HY7T-520-I
|
230v-50Hz
|
2200W
|
7 Ton
|
50-250mm
|
520mm
|
3.0L
|
IP 54
|
|
HY7T-520-II
|
230v-50Hz
|
2200W
|
7 Ton
|
50-250mm
|
520mm
|
3.0L
|
IP 54
|
|
HY7T-520-III
|
230v-50Hz
|
2200W
|
7 Ton
|
50-250mm
|
520mm
|
3.0L
|
IP 54
|
|
HY7T-520-IV
|
230v-50Hz
|
2200W
|
7 Ton
|
50-250mm
|
520mm
|
3.0L
|
IP 54
|
