Quick Details
-
Brand Name:
-
Yuejin
-
Motor Power:
-
130hp
-
Charging Capacity:
-
6.7CBM
-
Reclaiming capacity:
-
4CBM
-
Speed of Mixing Drum:
-
8r/min
-
Water Supply Mode:
-
Air pressure
-
After-sales Service Provided:
-
Overseas third-party support available, Free spare parts
-
Chassis brand:
-
Liuqi
-
Engine:
-
YC4S160-50
-
Drive form:
-
4*2
-
Reducer:
-
KEYI
-
Wheel base:
-
3600,3800mm
-
Hydraulic pump:
-
Changyuan
-
Hydraulic motor:
-
Dali
-
Radiator:
-
Zhenhua
-
Emissions standard:
-
Euro V
Quick Details
-
Mixing Power:
-
100L/MIN
-
Productivity:
-
other
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Yuejin
-
Motor Power:
-
130hp
-
Charging Capacity:
-
6.7CBM
-
Reclaiming capacity:
-
4CBM
-
Speed of Mixing Drum:
-
8r/min
-
Water Supply Mode:
-
Air pressure
-
After-sales Service Provided:
-
Overseas third-party support available, Free spare parts
-
Chassis brand:
-
Liuqi
-
Engine:
-
YC4S160-50
-
Drive form:
-
4*2
-
Reducer:
-
KEYI
-
Wheel base:
-
3600,3800mm
-
Hydraulic pump:
-
Changyuan
-
Hydraulic motor:
-
Dali
-
Radiator:
-
Zhenhua
-
Emissions standard:
-
Euro V
|
Vehicle Model |
EHY51 00 GJB N |
Vehicle Brand |
HUAYI |
|
Overall dimensions |
5995× 2200 × 3380 mm |
Curb weight |
4900 kg |
|
Loading capacity |
3-4 m3 |
|
|
|
Chassis parameters |
|||||
|
Chassis model |
NJ5100GJB |
Chassis brand |
YUEJIN |
||
|
Overall dimensions |
5500× 2200 × 2270 mm |
Wheel base |
3 3 00 mm |
||
|
Front/rear wheel track |
17 3 0/1 650 mm |
Front/rear suspension |
1150/1745 mm |
||
|
Approach/departure angle |
21/19 ° |
Maximum speed |
80 km/h |
||
|
Chassis Manufacturer |
Nanjing Automobile Group C o.,Ltd |
||||
|
Cab |
Configuration |
H300 a row and a half cab(with sleeping berth) , allowable 3 passengers |
|||
|
Color |
White ,other color is optional |
||||
|
Engine |
Model |
YCD4F2L-130 |
|||
|
Emission |
Euro 3 |
||||
|
Type |
4 cylinder s,in-line, verticle type, 4-stroke, water-cooled, turbo inter-cooling, direct injection, diesel engine |
||||
|
Rated power |
130hp,rated power speed 2800rpm |
||||
|
Displacement |
4214ml |
||||
|
Max.torque |
420N.m |
||||
|
Bore x stroke |
108x115mm |
||||
|
Manufacturer |
Guangxi Yuchai Power MachineryCo.,Ltd |
||||
|
Tire |
Size |
8.25-20 nylon tire |
|||
|
Number |
6 +1 nos |
||||
|
Brake |
Air brake |
||||
|
Front axle |
3.5T |
||||
|
Rear axle |
8T |
||||
|
Drive form |
4 X 2 |
||||
|
Rated voltage |
24V,DC |
||||
|
Transmissions |
8 speed forward 2 reverse |
||||
|
Steering device |
Power assisted steering |
||||
|
Steering wheel |
Left hand drive |
||||
|
Selective configuration |
S teel wire tire ,air conditioner |
||||
|
If there is a slight change in the chassis parameters above ,please take the actual product as the standard |
|||||
|
Concrete mixer truck structure parameters |
|||
|
Mixing capacity( m³ ) |
3-4 |
Color and Logo |
Optional |
|
Feeding speed ( m³ /min) |
≥ 3 |
Discharge speed(m³ /min) |
≥ 2 |
|
Discharge residual rate |
≤ 0.5% |
Slump scope(mm) |
50-210 |
|
Water tank capacity(L) |
300 |
Water pressure(Mpa) |
0.35-0.38 |
|
Tank material |
5mm alloy steel |
Tank front head |
6mm alloy steel |
|
Reducer |
Keyi |
Hydraulic motor |
Dali |
|
Hydraulic pump |
Changyuan |
Radiator |
Zhenhua |
|
Standard configuration |
chassis, sub frame ,mixer tank(main tank 5mm alloy steel wear resistant material,front tank head 6mm alloy steel wear resistant material), Keyi reducer, Changyuan hydraulic pump, Dali hydraulic motor,radiator,water tank,cleaning hose,feed port, discharge port,climbing ladder,air pressure water supply device. |
||
|
Selective configuration |
1, American SALI hydraulic pump, SALI hydraulic motor 2, Italy I nterpump hydraulic pump, hydraulic motor 3, Italy Bonfiglioli /Germany ZF reducer, Italy I nterpump hydraulic pump, hydraulic motor 4, Kaipeng Radiator |
||
