Quick Details
-
Engine Oil System Capacity:
-
1.1L
-
Maximum Torque:
-
28N.m
-
Bore *stroke:
-
90*66mm
-
Volume:
-
420cm3
-
Compression Ratio:
-
8.0:1
-
Min.Fuel Consumption:
-
325g/Kw/h
-
Air Cleaner:
-
Semi-dry .Oil bath .Dual.Silent .Cyclone
-
Dimension:
-
515*450*490mm
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Engine Type:
-
1-cylinder 4-stroke.Air-cooled. OHV
-
Fuel Capacity:
-
6.5L
-
Engine Oil System Capacity:
-
1.1L
-
Maximum Torque:
-
28N.m
-
Bore *stroke:
-
90*66mm
-
Volume:
-
420cm3
-
Compression Ratio:
-
8.0:1
-
Min.Fuel Consumption:
-
325g/Kw/h
-
Air Cleaner:
-
Semi-dry .Oil bath .Dual.Silent .Cyclone
-
Dimension:
-
515*450*490mm
| Model | LB188F | LB190F |
| Engine type | sinlge cylinder ,4-stroke ,OHV | sinlge cylinder ,4-stroke ,OHV |
| Bore*stroke | 88*64(mm) | 90*66(mm) |
| Volume | 389cm³ | 407cm³ |
| Compression ratio | 8.0:1 | 8.0:1 |
|
Maximum power output |
(13.0HP)9.6kw | (15.0HP)11kw |
|
Rated power output |
(11.7HP)8.6kw | (13HP)9.6kw |
| Maximum torque | 26.5N/m | 28N/m |
| Ignition system |
T.C.I (Transistor magneto) |
T.C.I (Transistor magneto) |
| Starting system | Recoil/electric | Recoil/electric |
|
Engine oil system capacity |
1.1 L | 1.1 L |
| Fuel capacity | 6.5 L | 6.5 L |
| Min.fuel consumption | 325g/kw/h | 325g/kw/h |
| Power output type | crankshaft 1:1 | crankshaft 1:1 |
|
The output axle steering |
Left | Left |
| Air cleaner |
Semi-dry,oil bath, dual , silent, cyclone |
Semi-dry,oil bath, dual , silent, cyclone |
| Dimensions | 495*420*505mm | 495*420*505mm |
| Net weight | 31kgs | 31kgs |
