Quick Details
-
Fork Length:
-
1220mm
-
Fork Width:
-
122mm
-
Overall Dimensions:
-
6300x2250x2500mm
-
Weight (KG):
-
7300 kg
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Shandong
-
Brand Name:
-
Topsense
-
Fork Length:
-
1220mm
-
Fork Width:
-
122mm
-
Overall Dimensions:
-
6300x2250x2500mm
-
Weight (KG):
-
7300 kg
Why Choose Us
Please attention
1. Factory direct price
2. Nice quality
3. 1 year warranty
4. OEM is acceptable
5. After sales service 24/7 hours
Customer's Feedback
Products Description
|
1
|
Overall length
|
5100mm
|
|
2
|
Overall length with fork
|
6300mm
|
|
3
|
Overall width
|
2250mm
|
|
4
|
Overall height
|
2500mm
|
|
5
|
Machine weight
|
7300KG
|
|
6
|
Cabine width
|
950mm
|
|
7
|
Wheel tread
|
1820mm
|
|
8
|
Wheel base
|
3400mm
|
|
9
|
Min. ground clearance
|
400mm
|
|
10
|
Outside turning radius
|
5000mm
|
|
11
|
Luffing angle
|
60°
|
|
12
|
Fork angle
|
45°
|
|
13
|
Tire
|
16/70-24
|
|
14
|
Fuel tank capacity
|
110L
|
|
15
|
Hydraulic tank capacity
|
75L
|
|
16
|
Max. speed
|
30km/h
|
|
17
|
Rated Load
|
3000kg
|
|
18
|
Max. lifting height
|
6950mm
|
|
19
|
Pressure of operation system
|
21apm
|
|
20
|
Engine emission standard
|
Euro II
|
|
21
|
Brand of engine
|
Yuchi
|
|
22
|
Engine Model
|
YCD4J22T-115
|
|
23
|
Rated power
|
85KW
|
|
24
|
Transmission system
|
hydrostatic
|
|
25
|
Drive method
|
4*4
|
