Quick Details
-
After-sales Service Provided:
-
Online support
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TOPFAN
-
Model Number:
-
MX***ABH1
-
Product name:
-
DC Brussless Fan
-
Bearing Type:
-
Sleeve/ 2Ball/ Hydraulic Bearing
-
Advantage:
-
silent
-
Application:
-
Industrial Equipment
-
Usage:
-
Air Cooling System
-
Motor:
-
Copper Motor
-
Function:
-
PWM FG
-
Size:
-
customized 15-280mm
-
Keyword:
-
Exhaust Cooling Fan
Quick Details
-
Applicable Industries:
-
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other
-
Electric Current Type:
-
DC
-
Mounting:
-
FREE STANDING
-
After-sales Service Provided:
-
Online support
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TOPFAN
-
Model Number:
-
MX***ABH1
-
Product name:
-
DC Brussless Fan
-
Bearing Type:
-
Sleeve/ 2Ball/ Hydraulic Bearing
-
Advantage:
-
silent
-
Application:
-
Industrial Equipment
-
Usage:
-
Air Cooling System
-
Motor:
-
Copper Motor
-
Function:
-
PWM FG
-
Size:
-
customized 15-280mm
-
Keyword:
-
Exhaust Cooling Fan
Product Details
Axial flow fan 15mm 20mm 30mm 40mm 50mm 60mm 70mm 80mm 90mm 110mm 120mm 140mm 150mm 160mm 172mm 200mm 225mm 254mm 280mm dc 5V mini silent 12V 24V or AC 110V 220V 380V industrial v
entilation
c
entrifugal fan blower
brushless
dc motor cooling fan
DC axial fan size vary from 15mm to 289mm
Free samples
can be provided before the mass production.
|
Model
|
Size
|
Rated Volt
|
Operating Volt
|
Rated Current
|
Input Power
|
Speed
|
Max. Airflow
|
Max. Static Pressure
|
Noise Level
|
||||||||
|
Part No.
|
MM
|
VDC
|
VDC
|
AMP
|
Watt
|
RPM
|
CFM
|
Pa
|
dB-A
|
||||||||
|
MX1504AYM5
|
15*04
|
3.3
|
2.8-3.6
|
0.03
|
0.1
|
10000
|
0.3
|
1.5
|
25
|
||||||||
|
MX2010AYL5
|
20*10
|
5
|
2.8-5.5
|
0.07
|
0.35
|
8000
|
0.42
|
8.73
|
21
|
||||||||
|
MX3010AYL5
|
30*10
|
5
|
3.0-6.5
|
0.1
|
0.5
|
6000
|
2.01
|
16.87
|
20
|
||||||||
|
MX4010ABD5
|
40*10
|
5
|
3.5-5.5
|
0.08
|
0.4
|
4000
|
4.39
|
14.32
|
21
|
||||||||
|
MX5010ABD5
|
50*10
|
5
|
3.5-5.5
|
0.15
|
0.75
|
4000
|
7.64
|
17.55
|
24
|
||||||||
|
MX6015ABU1
|
60*15
|
12
|
6.0-13.8
|
0.24
|
2.88
|
5700
|
24.2
|
52.27
|
39.5
|
||||||||
|
MX7015ABL1
|
70*15
|
12
|
6.0-13.8
|
0.13
|
1.56
|
2900
|
24.7
|
23.6
|
26.5
|
||||||||
|
MX8025ABU1
|
80*25
|
12
|
6.0-13.8
|
0.6
|
7.2
|
7400
|
73
|
177.6
|
48
|
||||||||
|
MX9238ZBL1
|
92*38
|
12
|
6.0-13.8
|
0.9
|
10.8
|
4500
|
102.73
|
145.04
|
45
|
||||||||
|
MX11037ABH1
|
110*37
|
12
|
6.0-13.8
|
0.13
|
1.56
|
2900
|
53
|
38
|
32.5
|
||||||||
|
MX12038ZBL1
|
120*38
|
12
|
6.0-13.8
|
3.0
|
36.0
|
6400
|
225
|
336
|
64
|
||||||||
|
MX14038ABU1
|
140*38
|
12
|
6.0-13.8
|
4.6
|
55.2
|
7600
|
310
|
640
|
70
|
||||||||
|
MX15051ABH1
|
150*51
|
12
|
6.0-13.8
|
2.42
|
29.04
|
4000
|
307.1
|
22.5
|
60.5
|
||||||||
|
MX17251ABU1
|
172*51
|
12
|
6.0-13.8
|
12.66
|
152
|
9200
|
545
|
1280
|
75
|
||||||||
|
MX20051ABU1
|
200*51
|
12
|
6.0-13.8
|
18.32
|
220
|
8500
|
1010
|
1488
|
82
|
||||||||
|
MX20060ABH1
|
200*60
|
12
|
6.0-13.8
|
3.5
|
42
|
3000
|
640
|
241.62
|
68
|
||||||||
|
MX22580ABH2
|
225*80
|
24
|
13.8-26.8
|
2.08
|
50
|
3000
|
588
|
1000
|
59
|
||||||||
|
MX25489ABH2
|
254*89
|
24
|
13.8-26.8
|
3.5
|
84
|
2600
|
890
|
251.58
|
68
|
||||||||
|
MX28080ABU2
|
280*80
|
24
|
15.0-27.0
|
6.2
|
148.8
|
3200
|
1234.7
|
276.4
|
75.6
|
||||||||
|
More Models
|
Other RPM/CFM/Voltage/Current...please contact us see the specification for more details.
|
|
|
|
|
|
|
|
|
||||||||
|
Product Name
|
DC AC EC Axial Fan
|
|
More Sizes
|
15mm 17mm 18mm 20mm 25mm 30mm 35mm 36mm 38mm 40mm 45mm 50mm 52mm 60mm 70mm 80mm 92mm 120mm 125mm 127mm 136mm 140mm 150mm 160mm 172mm 200mm 220mm 225mm 254mm 280mm ......
|
|
Material
|
Metal & Plastic
|
|
Bearing Type
|
Ball Bearing & Hydraulic Bearing & Sleeve Bearing
|
|
Voltage
|
DC 5V/12V/24V/48V ，AC 115V/230V/380V/480V , EC 115V/230V...
|
|
Function Range
|
PWM FG RD IP58 IP68
|
|
Applications
|
Household Appliances/Machine/Aeronautical/Power equipment, etc
|
|
Model
|
Size
|
Rated Volt
|
Operating Volt
|
Rated Current
|
Input Power
|
Speed
|
Max. Airflow
|
Max. Static Pressure
|
Noise Level
|
||||||||
|
Part No.
|
MM
|
VDC
|
VDC
|
AMP
|
Watt
|
RPM
|
CFM
|
Pa
|
dB-A
|
||||||||
|
MX7020GBH1
|
70*20
|
12
|
6.0-13.8
|
0.9
|
10.8
|
9200
|
39.9
|
560
|
61
|
||||||||
|
MX10042GBU1
|
100*42
|
12
|
6.0-13.8
|
2.56
|
30.8
|
6000
|
119
|
457.8
|
58.5
|
||||||||
|
MX12042GBU1
|
120*42
|
12
|
6.0-13.8
|
1.5
|
18
|
4000
|
120.2
|
308.7
|
51.5
|
||||||||
|
MX13382GBH1
|
133*82
|
12
|
6.0-13.8
|
2.4
|
28.8
|
4150
|
226
|
395
|
61
|
||||||||
|
MX15035GBH1
|
150*35
|
12
|
6.0-13.8
|
1.24
|
14.9
|
3800
|
135
|
410
|
59
|
||||||||
|
MX17569GBU1
|
175*69
|
12
|
6.0-13.8
|
14
|
168
|
5700
|
622
|
1100
|
80
|
||||||||
|
MX19069GBU4
|
190*69
|
48
|
36.8-60.5
|
3.08
|
148
|
4400
|
571
|
970
|
51.5
|
||||||||
|
MX22599GBH4
|
225*99
|
48
|
36.8-60.5
|
4.7
|
226
|
3500
|
1030
|
940
|
78
|
||||||||
|
MX25093GBU4
|
250*93
|
48
|
36.8-60.5
|
4.8
|
230
|
3100
|
965.3
|
750
|
73
|
||||||||
|
More Models
|
Other RPM/CFM/Voltage/Current...please contact us see the specification for more details.
|
|
|
|
|
|
|
|
|
||||||||
|
Product Name
|
Backward Curved Centrifugal Fan
|
|
More Sizes
|
70mm 100mm 133mm 150mm 175mm 190mm 225mm 250mm 280mm ......
|
|
Impeller Material
|
PA6 + GF / Aluminum Alloy / Plastic
|
|
Voltage
|
DC 5V/12V/24V/48V ，AC 115V/230V/380V/480V , EC 115V/230V...
|
|
Mode Of Operation
|
S1
|
|
Protection Class
|
IP55 / IP54 / IP44 PWM FG RD IP58 IP68
|
|
Insulation Class
|
F
|
|
Operation Temperature
|
-30℃ to +80℃
|
|
Techniacal Feature
|
Control input 0-10VDC / PWM, Tech ouput , Locked-rotor protection . Reverse Polarity Over-voltage protection Soft Start Protection
|
|
Model
|
Size
|
Rated Volt
|
Operating Volt
|
Rated Current
|
Input Power
|
Speed
|
Max. Airflow
|
Max. Static Pressure
|
Noise Level
|
||||||||
|
Part No.
|
MM
|
VDC
|
VDC
|
AMP
|
Watt
|
RPM
|
CFM
|
mm-
H₂O
|
dB-A
|
||||||||
|
MX1804GYM5
|
18*04
|
5
|
2.8-5.5
|
0.045
|
0.23
|
11000
|
0.2
|
5.16
|
35
|
||||||||
|
MX3010GYU5
|
30*10
|
5
|
3.0-6.5
|
0.28
|
1.4
|
12000
|
4.15
|
6.35
|
30
|
||||||||
|
MX4010GSU5
|
40*10
|
5
|
4.0-6.0
|
0.21
|
1.05
|
8600
|
3.1
|
0.572
|
34.5
|
||||||||
|
MX5015GBH5
|
50*15
|
5
|
4.5-5.5
|
0.3
|
1.5
|
4200
|
3.92
|
9.05
|
35
|
||||||||
|
MX6015GBH5
|
60*15
|
5
|
4.5-5.5
|
0.35
|
1.75
|
3500
|
5.89
|
10.42
|
33.5
|
||||||||
|
MX7530GBU1
|
60*15
|
12
|
6.0-13.8
|
0.55
|
6.6
|
4500
|
19.5
|
30.7
|
49.5
|
||||||||
|
MX9733GBU1
|
97*33
|
12
|
6.0-13.8
|
6.2
|
74.4
|
8200
|
65.3
|
198.9
|
69
|
||||||||
|
MX12032GBM1
|
120*32
|
12
|
6.0-13.8
|
2.3
|
27.6
|
3850
|
56.5
|
127.5
|
62
|
||||||||
|
MX14040GBU1
|
140*40
|
12
|
6.0-13.8
|
2.2
|
26.4
|
5600
|
104.1
|
82.5
|
75.5
|
||||||||
|
More Models
|
Other RPM/CFM/Voltage/Current...please contact us see the specification for more details.
|
|
|
|
|
|
|
|
|
||||||||
|
Product Name
|
DC AC EC Centrifugal Blower
|
|
More Sizes
|
18mm 20mm 25mm 30mm 35mm 40mm 50mm 51mm 52mm 60mm 75mm 77mm 81mm 85mm 93mm 97mm 120mm 140mm ......
|
|
Material
|
Housing - Galvanized Metal Impeller - Galvanized Metal & Plastic
|
|
Motor Type
|
AC Capacitor Motor , DC/EC brushless external rotor motor
|
|
Voltage
|
DC 5V/12V/24V/48V ，AC 115V/230V/380V/480V , EC 115V/230V...
|
|
Function Range
|
PWM FG RD IP58 IP68
|
|
Applications
|
split air conditioner , air curtains , cooling, etc
|
