Quick Details
-
Graphic Format Supported:
-
AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
VOIERN
-
Dimension(L*W*H):
-
140*75*(58+38)CM
-
Weight (KG):
-
85 KG
-
Product name:
-
C02 Laser Engraving Cutting Machine
-
Keywords:
-
6040 Laser Engraving Cutting Machine
-
Function:
-
Cutting Engraving Non-metal Materials
Quick Details
-
Engraving Area:
-
600*400mm
-
Laser Type:
-
CO2
-
Engraving Speed:
-
1-1000mm/s
-
Graphic Format Supported:
-
AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
VOIERN
-
Dimension(L*W*H):
-
140*75*(58+38)CM
-
Weight (KG):
-
85 KG
-
Product name:
-
C02 Laser Engraving Cutting Machine
-
Keywords:
-
6040 Laser Engraving Cutting Machine
-
Function:
-
Cutting Engraving Non-metal Materials
Product Description
Our products can be selected according to the customer's work needs.
Advantages of CO 2 laser engraving:
1. Wide range: carbon dioxide laser can carve and cut almost any non-metallic material. And the price is low!
2. Safe and reliable: non-contact processing will not cause mechanical extrusion or mechanical stress to materials. No "knife mark", no damage to the surface of the workpiece; no deformation of the material;
3. Precision and delicacy: the machining accuracy can reach 0.02mm;
4. Saving environmental protection: the diameter of light beam and spot is small, generally less than 0.5mm; cutting and
processing saves materials, safety and health;
5. Consistent effect: ensure that the processing effect of the same batch is completely consistent.
6. High speed and fast: high speed carving and cutting can be carried out immediately according to the drawings output by the computer.
7. Low cost: not limited by the processing quantity, laser processing is cheaper for small batch processing services.
1. Wide range: carbon dioxide laser can carve and cut almost any non-metallic material. And the price is low!
2. Safe and reliable: non-contact processing will not cause mechanical extrusion or mechanical stress to materials. No "knife mark", no damage to the surface of the workpiece; no deformation of the material;
3. Precision and delicacy: the machining accuracy can reach 0.02mm;
4. Saving environmental protection: the diameter of light beam and spot is small, generally less than 0.5mm; cutting and
processing saves materials, safety and health;
5. Consistent effect: ensure that the processing effect of the same batch is completely consistent.
6. High speed and fast: high speed carving and cutting can be carried out immediately according to the drawings output by the computer.
7. Low cost: not limited by the processing quantity, laser processing is cheaper for small batch processing services.
|
Water chiller
|
Water chiller has a better cooling effect, which will let machine and laser tube have a longer service life.
|
|
Blade work platform
|
It can reduce the reflection of light and make the engraving effect better.
|
|
Chuck
|
Chuck Rotary is for irregular objects, like tapered, etc.Non-standard Chuck Rotary is for regular objects, like rounded,
cylindrical, etc. |
Applicable Material
♦Acrylic ♦Crytal ♦Glass ♦Leather ♦MDF ♦Paper ♦Plastic ♦Plexiglass ♦Plywood ♦Rubber
♦Stone ♦Wood ♦Other non-metal
Our products are widely applicable and well carved.
Detailed Images
The main parts of our products are high-quality industrial-grade accessories.
1. Laser Head
-- Laser head can stop focus lens from polluting.
-- Laser head will make effect of engraving and cutting better.
2.Sealed-off Glass CO2 Laser Tube
-- Longer service life.
-- More steady.
-- Higher efficiency.
-- High precision.
-- Small facula.
3. Electric Up-down Work Table .
-- Work table can be Up and Down freely to put higher objects in this machine.
4. Stepper Motor
-- Leadshine brand.
-- High torque.
-- Low heat.
-- Low running noise.
-- Stable operation .
5. X-Y Plotter
-- Taiwan HIWIN brand.
-- Linear square guideway.
-- High speed and high precision.
-- Long service life.
-- Linear square guideway.
-- High speed and high precision.
-- Long service life.
6. Control Panel and Mainboard
-- RuiDa brand. It's famous and popular.
-- It has their own system for engraving and cutting. Don't need to install extra work software.
-- It has multi-language function.
-- It has an ability to choose intelligently a good work path to engrave and cut.
-- It has their own system for engraving and cutting. Don't need to install extra work software.
-- It has multi-language function.
-- It has an ability to choose intelligently a good work path to engrave and cut.
Size Information
Cutting depth of different power and material.Please choose the product according to your needs.
Related Products
Parameter table
|
Cutting Speed
|
1-70mm/s
|
|
Highest Scanning Precision
|
≤1000DPI
|
|
Resolution Ratio
|
<0.01mm
|
|
Location Precision
|
<0.01mm
|
|
Min. Shaping Character Letter
|
1.0 x 1.0mm
|
|
Working Temperature
|
0-45°C
|
|
Working Humidity
|
5-95%
|
|
Power Supply
|
AC220V±10% /50HZ , AC110V±10%//60HZ
|
|
Laser Wave Length
|
10.6um
|
|
Water Cut-off Protection Device
|
Yes
|
|
Work Table
|
Multifunctional work table and honeycomb work table
|
|
Electric Up/down Working Table
|
Yes
|
|
Range of Electric Up-down (Z)
|
0-300mm
|
|
Motor
|
42 Stepper Motor
|
|
Digital Subdivision Stepper Drive
|
System Supported
|
|
DSP
Interface |
USB 2.0
|
|
Auxiliary Device
|
Exhaust Fan, Exhaust Pipe,Water Pump,Air Pump,User Manual
|
|
Optional Accessories
|
Simple rotation, standard chuck, chiller,auto focus system,Water Protection,CCD camera,Blade work platform
|
Packing&Shipping
We serve the whole process from production to transportation.
Company Introduction
Voiern Laser Technology is located in Liaocheng High-tech Industrial Development Zone. Our company is mainly committed to research, development and production of laser engraving, cutting and marking machines in many fields. Covering R&D, production,sales, and customization of various high-end laser equipment.The products are mainly used in scientific research teaching andelectronic materials, LEDs, advertising materials, medical supplies, handicrafts, textiles,clothing, footwear, auto parts,furniture, and other industrial fields.
Our Services & Strength
1.We provide you the friendly English User manual or operating videos for free.
2.24 hours technical support by email or calling.
3.Warranty: 1 year free, 2-3 years cost price and free technical support always.
4.Free training to make sure you master the operating of our products.
5. OEM/ODM accept .
2.24 hours technical support by email or calling.
3.Warranty: 1 year free, 2-3 years cost price and free technical support always.
4.Free training to make sure you master the operating of our products.
5. OEM/ODM accept .
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
