Quick Details
-
Warranty:
-
12 years
-
Brand Name:
-
GAMKO
-
Model Number:
-
GKA60P280
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1640 x 992 x 35 mm
-
Cell Type:
-
Poly-crystalline 156 x 156mm (6 inch)
-
No.of cells:
-
60 (6 x 10)
-
Dimensions:
-
1640 x 992 x 35mm (64.57 x 39.05 x 1.38 inch)
-
Weight:
-
19.0 kg (41.9 lbs)
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP67 Rated
-
Voltage at Nominal Power (Vmp):
-
31.5V
-
Current at Nominal Power (Imp):
-
8.89A
-
Application:
-
home use, commercial, industrial
-
Certificate:
-
CE/FCC/RoHS
Quick Details
-
Cell size:
-
156.75mmx156.75mm
-
Type:
-
Full cell, Standard Solar Panel
-
Panel Efficiency:
-
18%
-
Warranty:
-
12 years
-
Brand Name:
-
GAMKO
-
Model Number:
-
GKA60P280
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1640 x 992 x 35 mm
-
Cell Type:
-
Poly-crystalline 156 x 156mm (6 inch)
-
No.of cells:
-
60 (6 x 10)
-
Dimensions:
-
1640 x 992 x 35mm (64.57 x 39.05 x 1.38 inch)
-
Weight:
-
19.0 kg (41.9 lbs)
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP67 Rated
-
Voltage at Nominal Power (Vmp):
-
31.5V
-
Current at Nominal Power (Imp):
-
8.89A
-
Application:
-
home use, commercial, industrial
-
Certificate:
-
CE/FCC/RoHS
Product Description
| MECHANICAL CHARACTERISTICS |
| Cell type Polycrystalline 5BB 156x156mm (6x6inches) |
| Number of cells 60 (6x10) |
| Module dimensions 1640x992x35mm (64.57x39.06x1.38inches) |
| Weight 18kg (39.7lbs) |
| Front cover 3.2mm (0.13inches) tempered glass with AR coating |
| Frame Anodized aluminum alloy |
| Junction box IP67, 3 diodes |
| Cable 4mm2 (0.006inches2), 900mm (35.43inches) |
| Connector compatible |
*We produce solar panels
*Grade A sufficient power poly and mono solar panels
*Grade A sufficient power 156*156 solar cells
*Silicon wafer
*We supplier solar inverter and other solar products.
*Style:Household, commercial, industrial
*High-end with good quality, excellent in workmanship, best service
