Quick Details
-
Power Source:
-
Electric, Solar, Manual, Vehicle Power Supply
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
STARK
-
Model Number:
-
STK-CFC-serise
-
Power (W):
-
no
-
Voltage (V):
-
no
-
Product name:
-
Cartridge water filter element
-
Material:
-
PP / Plastic
-
Function:
-
Water Purification Plant
-
Filter Media:
-
Polypropylene
-
Micron:
-
0.1um, 0.22um, 0.45um, 1um,3um, 5um, 10um,20um, 30um,50um
-
Length:
-
10" 20" 30"40"
-
Connection:
-
222/226 Flat/Fin
-
Usage:
-
Microelectronics, pharmaceutical industry water
-
Certification:
-
ce
Quick Details
-
After-sales Service Provided:
-
Free spare parts, Field maintenance and repair service, Onsite Installation, Return and Replacement
-
Warranty:
-
1 Year
-
Application:
-
Hotel, Car, Outdoor, Garage, RV, Commercial, Household
-
Power Source:
-
Electric, Solar, Manual, Vehicle Power Supply
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
STARK
-
Model Number:
-
STK-CFC-serise
-
Power (W):
-
no
-
Voltage (V):
-
no
-
Product name:
-
Cartridge water filter element
-
Material:
-
PP / Plastic
-
Function:
-
Water Purification Plant
-
Filter Media:
-
Polypropylene
-
Micron:
-
0.1um, 0.22um, 0.45um, 1um,3um, 5um, 10um,20um, 30um,50um
-
Length:
-
10" 20" 30"40"
-
Connection:
-
222/226 Flat/Fin
-
Usage:
-
Microelectronics, pharmaceutical industry water
-
Certification:
-
ce
Product Description
PP pleated cartridge
The filter element adopts a full polypropylene structure with a wide range of chemical compatibility, and can be used to filter most acids, alkalis and solvents. The scientifically designed filter structure makes the filter element have the characteristics of high flow rate and high dirt holding capacity, which can greatly extend the service life of the terminal filter element. It is an economical and efficient pre-filter element.
Element use for ---
The product can be customized according to the actual process fluid characteristics or customer needs to improve the efficiency of the filtration process and reduce the cost of use.
Features
-All polypropylene structure -Wide chemical compatibility -High flow rate and high dirt holding capacity design
-Economical and efficient pre-filtration product
Structural materials
Filter material: Polypropylene.
Support / Diversion Layer: Polypropylene
Housing/Center Rod/End Cap: Polypropylene
Sealing Technology: Hot-melt welding (no adhesive)
Support / Diversion Layer: Polypropylene
Housing/Center Rod/End Cap: Polypropylene
Sealing Technology: Hot-melt welding (no adhesive)
Technical performance
Filtration accuracy: 0.1~ 50μm Maximum operating pressure difference: 4.0bar @ 20°C, 2.0bar @ 85°C
Maximum operating temperature: 85°C Recommended to replace the pressure difference: 2.0bar
Typical application
-food and drink
-Chemicals & raw materials
-Machining
-Microelectronics
-Pharmaceutical & Biological Products
-Industrial water
Cartridge filter system
Stainless steel security filter (also known as precision filter), the shell of the cylinder is generally made of stainless steel,and the interior uses PP melt blown, wire-fired, folded, titanium filter, activated carbon filter and other tubular filter elements as filter elements. Filter media and design process choose different filter elements to meet the requirements of effluent water quality. The body can also choose a quick-installation type for convenient and quick replacement of the filter element and cleaning. This equipment is used in pharmaceutical, chemical, food, beverage, water treatment, brewing, petroleum, printing and dyeing, environmental protection and other industries. It is a kind of equipment for filtering, clarifying, and purifying liquids.
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
