Quick Details
-
Warranty(Year):
-
5-Year
-
Color Temperature(CCT):
-
3000K/4000K/ 5000K/6000K
-
Product Weight（kg）:
-
1
-
Input Voltage(V):
-
220-240, AC 220V( ± 10%)
-
Lamp Luminous Flux(lm):
-
500lm
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-15 - 40
-
Working Lifetime(Hour):
-
30000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
wiscoon
-
Model Number:
-
APE-2
-
Product name:
-
LED High Bay
-
Power:
-
100W~200W
-
Beam Angle:
-
60/90/120 Degree
-
PF:
-
0.95
-
Light Efficiency:
-
160LM/W
-
Certification:
-
ce, FCC, GS, RoHS
-
LED Chip:
-
Epistar
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
110
-
Application:
-
Kitchen
-
Lamp Body Material:
-
Aluminum frame+Prisnatic diffuser
-
Warranty(Year):
-
5-Year
-
Color Temperature(CCT):
-
3000K/4000K/ 5000K/6000K
-
Product Weight（kg）:
-
1
-
Input Voltage(V):
-
220-240, AC 220V( ± 10%)
-
Lamp Luminous Flux(lm):
-
500lm
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-15 - 40
-
Working Lifetime(Hour):
-
30000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
wiscoon
-
Model Number:
-
APE-2
-
Product name:
-
LED High Bay
-
Power:
-
100W~200W
-
Beam Angle:
-
60/90/120 Degree
-
PF:
-
0.95
-
Light Efficiency:
-
160LM/W
-
Certification:
-
ce, FCC, GS, RoHS
-
LED Chip:
-
Epistar
Products Description
Product details
|
Size
|
φ120*38mm
|
φ170*38mm
|
φ225*38mm
|
φ240*38mm
|
φ300*38mm
|
|
Model
|
APE-2-A-120-6
|
APE-2-A-170-12
|
APE-2-A-225-18
|
APE-2-A-240-20
|
APE-2-A-300-24
|
|
Rated Power(±5%)
|
6W Typical
|
12W Typical
|
18W Typical
|
20W Typical
|
24W Typical
|
|
Input Voltage
|
200-240V/AC Typical
100-277V/AC optional |
200-240V/AC Typical
100-277V/AC optional |
200-240V/AC Typical
100-277V/AC optional |
200-240V/AC Typical
100-277V/AC optional |
200-240V/AC Typical
100-277V/AC optional |
|
Frenquency
|
50/60Hz
|
50/60Hz
|
50/60Hz
|
50/60Hz
|
50/60Hz
|
|
Power Factor
|
>0.9
|
>0.9
|
>0.9
|
>0.9
|
>0.9
|
|
Power Efficiency
|
86%
|
86%
|
86%
|
86%
|
86%
|
|
THD
|
<20%
|
<20%
|
<20%
|
<20%
|
<20%
|
|
Flicker Free
|
Flicker(Standard)
Flicker Free(Optional) |
Flicker(Standard)
Flicker Free(Optional) |
Flicker(Standard)
Flicker Free(Optional) |
Flicker(Standard)
Flicker Free(Optional) |
Flicker(Standard)
Flicker Free(Optional) |
|
Dimming
|
TRIAC/ Tuya APP can be customized
|
TRIAC/ Tuya APP can be customized
|
TRIAC/ Tuya APP can be customized
|
TRIAC/ Tuya APP can be customized
|
TRIAC/ Tuya APP can be customized
|
|
Sensor/Emergency
|
Can be customized
|
Can be customized
|
Can be customized
|
Can be customized
|
Can be customized
|
|
Driver Brand
|
Llifud/BOKE/WISCOON
|
Llifud/BOKE/WISCOON
|
Llifud/BOKE/WISCOON
|
Llifud/BOKE/WISCOON
|
Llifud/BOKE/WISCOON
|
|
Function
|
Blueteeth/App control can be customized
|
Blueteeth/App control can be customized
|
Blueteeth/App control can be customized
|
Blueteeth/App control can be customized
|
Blueteeth/App control can be customized
|
|
LED brand
|
Sanan optoelectronics/Wafer
|
Sanan optoelectronics/Wafer
|
Sanan optoelectronics/Wafer
|
Sanan optoelectronics/Wafer
|
Sanan optoelectronics/Wafer
|
|
Typical CCT
|
3000K/4000K/5000K/6000K
|
3000K/4000K/5000K/6000K
|
3000K/4000K/5000K/6000K
|
3000K/4000K/5000K/6000K
|
3000K/4000K/5000K/6000K
|
|
CRI
|
>80Ra Typical
|
>80Ra Typical
|
>80Ra Typical
|
>80Ra Typical
|
>80Ra Typical
|
|
CCT Adjustable
|
Can be customized
|
Can be customized
|
Can be customized
|
Can be customized
|
Can be customized
|
|
Lumens Efficiency(lm/w)
|
75-85lm/w
|
75-85lm/w
|
75-85lm/w
|
75-85lm/w
|
75-85lm/w
|
|
Luminous Flux(±5%)
|
500lm
|
950lm
|
1400lm
|
1600lm
|
1900lm
|
|
LED Type
|
LM80 SMD/1W
|
LM80 SMD/1W
|
LM80 SMD/1W
|
LM80 SMD/1W
|
LM80 SMD/1W
|
|
Chipset brand
|
12PCS
|
20PCS
|
24PCS
|
28PCS
|
36PCS
|
|
Beam Angle
|
120°
|
120°
|
120°
|
120°
|
120°
|
|
Lens
|
/
|
/
|
/
|
/
|
/
|
|
Glare Index
|
/
|
/
|
/
|
/
|
/
|
|
Materials
|
Aluminum+PS
|
Aluminum+PS
|
Aluminum+PS
|
Aluminum+PS
|
Aluminum+PS
|
|
Lifespan
|
50,000hours
|
50,000hours
|
50,000hours
|
50,000hours
|
50,000hours
|
|
Standards
|
CE/ROHS/FCC/ETL
|
CE/ROHS/FCC/ETL
|
CE/ROHS/FCC/ETL
|
CE/ROHS/FCC/ETL
|
CE/ROHS/FCC/ETL
|
|
Warranty
|
3years
|
3years
|
3years
|
3years
|
3years
|
|
IP Grade
|
IP20
|
IP20
|
IP20
|
IP20
|
IP20
|
|
Storage Temperature
|
-30~60℃(-22~140℉)
|
-30~60℃(-22~140℉)
|
-30~60℃(-22~140℉)
|
-30~60℃(-22~140℉)
|
-30~60℃(-22~140℉)
|
|
Working Temperature
|
-20~40℃(-4~104℉)
|
-20~40℃(-4~104℉)
|
-20~40℃(-4~104℉)
|
-20~40℃(-4~104℉)
|
-20~40℃(-4~104℉)
|
|
Operating Humidity
|
10%
|
10%
|
10%
|
10%
|
10%
|
|
Product Size
|
φ120*120*H38mm
|
φ170*170*H38mm
|
φ225*225*H38mm
|
φ240*240*H38mm
|
φ300*300*H38mm
|
|
Product N.W
|
0.26kg
|
0.43kg
|
0.68kg
|
0.97kg
|
1.075kg
|
|
Packing Size
(*PCS/CTN) |
46*28*28cm (50PCS/CTN)
|
48*38.5*37.5cm(40PCS/CTN)
|
49*46*26cm(18PCS/CTN)
|
63.5*48.5*34cm(20PCS/CTN)
|
63.5*48.5*34cm(20PCS/CTN)
|
|
Gross Weight/CTN
|
13kg
|
17.2kg
|
12.3kg
|
19.5kg
|
21.5kg
|
