Quick Details
-
Power (kW):
-
44
-
Type:
-
Grinding equipment
-
sharpened:
-
8~10 times/3500 hours
-
Name:
-
Fine powder grinder
-
capacity:
-
100kg-150kg/h
-
Function:
-
Tire Powder Recycling Machine
-
Raw material:
-
Waste Tyre
-
Shippment:
-
By sea
-
Application:
-
Rubbers Recycling Industry
-
Advantage:
-
long service time
-
Keyword:
-
tyre shredding machine tire recycling machine
Quick Details
-
Place of Origin:
-
China
-
Marketing Type:
-
New Product 2023
-
Weight (KG):
-
8000 kg
-
Power (kW):
-
44
-
Type:
-
Grinding equipment
-
sharpened:
-
8~10 times/3500 hours
-
Name:
-
Fine powder grinder
-
capacity:
-
100kg-150kg/h
-
Function:
-
Tire Powder Recycling Machine
-
Raw material:
-
Waste Tyre
-
Shippment:
-
By sea
-
Application:
-
Rubbers Recycling Industry
-
Advantage:
-
long service time
-
Keyword:
-
tyre shredding machine tire recycling machine
Product Description
Two shaft shredders is a kind of industrial shredder specially designed for metal scraps, with low speed, high torque, minimum noise and power consumption, but high productive rate.
All the shredder blades thickness ranges from 25mm-152mm depending on the raw material and final size, while capacity ranges from 1~30 tons per hour.
Technical Parameter
|
Model
|
Input size
|
Output size
|
Capacity
|
Motor
|
Weight
|
|
TS-800
|
800mm
|
50*50mm
|
1-2t/h
|
2*22kw
|
8t
|
|
TS-1200
|
1200mm
|
60*60mm
|
3-5t/h
|
2*37kw
|
14t
|
|
TS-1600
|
1600mm
|
50-150mm
|
6-8t/h
|
2*45kw
|
18t
|
|
TS-1800
|
1800mm
|
50-150mm
|
7-10t/h
|
2*55kw
|
23t
|
Detailed Images
☑
Replaceable blade bit tool is fixed by both screws and grooves on the blade base, so the screws won’t get loosen.
☑ Blades are made one of best material 9Cr2Mo, long service life.
☑
The transmission parts are connected by coupling to reduce vibration and protect the main shaft and reducer from force loss.
☑ Planetary reducer is equipped with high accuracy, high loading power, high speed ratio, durable use, low noise, low vibration and low inertia.
☑ Driven by SIEMENS motor, quality and power guaranteed.
☑
The shredded chips from prime shredder will drop on the rotary screen, and small chips will fall on the conveying belt, the big chips will be feed in the shredder for shredding and recycling again. The final chips will be around 50~60mm.
☑
Super easy operation with buttons and emergency stop functions.
Product Paramenters
Rubber Grinder
Input materials≤50mm tire rubber blocks Finally products ≤20mm. and can remove 96% of the tire steel wire Motor: as per request Reducer: as per request
|
Rasper
|
LK-R315
|
LK-R132
|
LK-R90
|
LK-R75
|
LK-R55
|
LK-R45
|
|||||
|
Motor
|
Siemens
|
Siemens
|
Siemens
|
Siemens
|
Siemens
|
Siemens
|
|||||
|
Power
|
315kw
|
132kw
|
90kw
|
75w
|
55w
|
45kw
|
|||||
|
Voltage
|
As per request
|
As per request
|
As per request
|
As per request
|
As per request
|
As per request
|
|||||
|
Cutting chamber
|
697*1562
|
742*1200
|
550*1000
|
550*800
|
450*800
|
45-*600
|
|||||
|
Equipment dimensions mm
|
6217*2168*3561
|
2010*2562*4110
|
2095*2180*4105
|
1995*1980*4105
|
1720*1730*2316
|
1400*1200*2260
|
|||||
|
Hopper opening
|
1726*877*906
|
1412*902*1410
|
1182*700*1255
|
982*700*1255
|
922*580*916
|
722*580*916
|
|||||
|
Equipment weight
|
24000kg
|
6100kg
|
4200kg
|
3500kg
|
1850kg
|
1700kg
|
|||||
|
Capacity
|
3-6T/H
|
1.5-3T/H
|
1-1.5T/H
|
700KG-1T/H
|
500-700KG/H
|
300-500KG/H
|
|||||
|
Final product
|
10-30mm
|
10-30mm
|
10-30mm
|
10-30mm
|
10-30mm
|
10-30mm
|
|||||
Steel Wire Separator
The rubber grinder is a device that pulverizes 2-6mm pure rubber granules into a fine powder of10-140 mesh at room temperature. Motor: as per request
Product size: one or more sizes are discharged at the same time
|
Granulator
|
LK-G90
|
LK-G45
|
LK-G37
|
LK-R75
|
LK-R55
|
LK-R45
|
|||||
|
Motor specifications
|
Electric-Siemens
|
Electric-Siemens
|
Electric-Siemens
|
Siemens
|
Siemens
|
Siemens
|
|||||
|
Power
|
90kw
|
45kw
|
37kw
|
75w
|
55w
|
45kw
|
|||||
|
Voltage
|
As per request
|
As per request
|
As per request
|
As per request
|
As per request
|
As per request
|
|||||
|
Cutting chamber L*W
|
742*1200
|
580*1000
|
580*800
|
550*800
|
450*800
|
45-*600
|
|||||
|
Equipment Dimensions
|
2150*2250*2950
|
1765*1900*2435
|
1765*1660*2435
|
1995*1980*4105
|
1720*1730*2316
|
1400*1200*2260
|
|||||
|
Equipment weight
|
5600kg
|
3300kg
|
2950kg
|
982*700*1255
|
922*580*916
|
722*580*916
|
|||||
|
Hopper opening L*W*H
|
895*1434*1160
|
602*994*916
|
602*794*916
|
3500kg
|
1850kg
|
1700kg
|
|||||
|
Capacity
|
800-1500kg/h
|
500-800kg/h
|
300-500kg/h
|
700KG-1T/H
|
500-700KG/H
|
300-500KG/H
|
|||||
|
Final product
|
1-6mm
|
1-6mm
|
1-6mm
|
10-30mm
|
10-30mm
|
10-30mm
|
|||||
|
Miller
|
LK-M280
|
|
Motor Specifications
|
Electric-Siemens
|
|
Power
|
30Kw*4
|
|
Voltage
|
as per request
|
|
Equipment Dimensions L*W*H
|
2404*1100*1093
|
|
Equipment Weight
|
5000Kg
|
|
Capacity
|
400-600kg/hr
|
|
Final Product
|
30-120 mesh
|
4.
Before Sale:
|
1. Fast Response
|
All customer’s messages will be replied within 24 hours
|
|
2. Free Consulting
|
We can provide free consulting services of tire recycling machines
|
|
3. Customized Layout
|
We will make the layout compatible to your working site
|
|
4. OEM/ODM
|
We can personalized the equipment with your brand
|
|
5. Engineer Support
|
Our engineer will always participate during and after the trading
|
|
6.Brand New Equipment
|
We can guarantee every component is new and high quality brand
|
|
7. Logistic Team
|
We can transport the machine by sea, by train or by land
|
4.
AFTER Sale:
|
1. Commissioning
|
We will test the machines before shipment and provide videos
|
|
2. Components Supply
|
We can guarantee stable supply of consumable components
|
|
3. Custom Clearance Support
|
We will provide PI, CI, PL, contract, CO, etc for your custom clearance
|
|
4. Product Manual
|
We will offer you operation manual of the machines
|
|
5. Installation
|
according to the customer’s requirement, After machine reach the customer's working site, We will assemble the main parts,we will send engineers for the installation, commissioning and training
|
|
|
|
|
7. Logistic Team
|
We can transport the machine by sea, by train or by land
|
Customer feedback
Why Choose Us
Zhengzhou Harvest Machinery Co., Ltd
HVET's main focus is to provide our customer cost-effective waste recycling system applied in all kinds of waste recycling like tire/plastic/wood/metal/car/pcb board recycling and could provide output products like chips(50-150mm), mulches( 10-30mm), granules (1-6mm), powder (30-120 mesh) and other size as customer required. HVET also offers machines for specialized markets. The most important to theHVET family of products is the Tire Shredding System. These machines are designed to process used car and truck tires. We offer complete systems to produce separated crumb or powder.
