Quick Details
-
Power:
-
1.1KW
-
Min. Lifting Height:
-
6M
-
Table Size:
-
1200*630*1100
-
Overall Dimensions:
-
1553*850*2000
-
Weight:
-
340 kg, 340KG
-
Product name:
-
Scissor Lift Platform
-
Type:
-
Hydraulic Cylinder Drive
-
Keywords:
-
Hydraulic Vehicle-mounted Elevating Platform
-
Lift Drive:
-
AC Power
-
Lifting system:
-
Electric Hydraulic
-
Electric Hydraulic:
-
500kg/customized
-
Name:
-
Scissor Lift Platform
-
Color:
-
Customization
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
xiaogangjianji
-
Power:
-
1.1KW
-
Min. Lifting Height:
-
6M
-
Table Size:
-
1200*630*1100
-
Overall Dimensions:
-
1553*850*2000
-
Weight:
-
340 kg, 340KG
-
Product name:
-
Scissor Lift Platform
-
Type:
-
Hydraulic Cylinder Drive
-
Keywords:
-
Hydraulic Vehicle-mounted Elevating Platform
-
Lift Drive:
-
AC Power
-
Lifting system:
-
Electric Hydraulic
-
Electric Hydraulic:
-
500kg/customized
-
Name:
-
Scissor Lift Platform
-
Color:
-
Customization
Product Description
Specification
|
product name
|
model
|
Work Height (M)
|
Capacity(KG)
|
Platform（M）
|
voltage（V）
|
power（kw）
|
Weight（kg）
|
Dimensions(m)
|
|
Single
column |
GTWY4-100-1
|
4
|
100
|
0.65*0.65
|
220V
|
1.1
|
280
|
1.42*0.78*1.97
|
|
|
GTWY4-100-lmn
|
4
|
100
|
0.64*0.49
|
220V
|
1.1
|
/
|
1.45*0.6*1.63
|
|
|
GTWY6-100-1
|
6
|
150
|
0.65*0.65
|
220V
|
1.1
|
360
|
1.42*0.78*1.97
|
|
|
GTWY6-100-1mn
|
6
|
150
|
0.65*0.5
|
220V
|
1.1
|
/
|
1.45*0.6*1.63
|
|
|
GTWY8-100-1
|
8
|
130
|
0.65*0.65
|
220V
|
1.1
|
380
|
1.42*0.78*1.97
|
|
|
GTWY10-100-1
|
10
|
130
|
0.65*0.65
|
220V
|
1.1
|
420
|
1.42*0.78*1.97
|
|
Double
column |
GTWY6-200-2
|
6
|
300
|
1.2*0.63
|
220V
|
1.5
|
510
|
1.55*0.85*2.0
|
|
|
GTWY8-200-2
|
8
|
300
|
1.2*0.63
|
220V
|
1.5
|
550
|
1.55*0.85*2.0
|
|
|
GTWY10-200-2
|
10
|
250
|
1.5*0.63
|
220V
|
1.5
|
690
|
1.84*0.85*2.0
|
|
|
GTWY12-200-2
|
12
|
200
|
1.5*0.63
|
220V
|
1.5
|
730
|
1.84*0.85*2.0
|
|
|
GTWY14-200-2
|
14
|
150
|
1.5*0.63
|
220V
|
1.5
|
790
|
1.95*1.05*2.39
|
|
three
column |
GTWY12-250-3
|
12
|
200
|
1.57*0.9
|
220/380
|
2.2
|
1050
|
1.9*1.1*1.98
|
|
|
GTWY14-200-3
|
14
|
200
|
1.57*0.9
|
220/380
|
2.2
|
1120
|
1.9*1.2*2.3
|
|
|
GTWY16-200-3
|
16
|
200
|
1.57*0.9
|
220/380
|
2.2
|
1200
|
2.0*1.2*2.7
|
|
Four
column |
GTWY12-250-4
|
12
|
200
|
1.57*0.9
|
220/380
|
2.2
|
1050
|
1.9*1.2*2.0
|
|
|
GTWY14-200-4
|
14
|
200
|
1.57*0.9
|
220/380
|
2.2
|
1150
|
1.9*1.2*2.3
|
|
|
GTWY16-200-4
|
16
|
200
|
1.57*0.9
|
220/380
|
2.2
|
1250
|
1.9*1.2*2.7
|
|
|
GTWY18-250-4
|
18
|
200
|
1.57*0.9
|
220/380
|
2.2
|
1480
|
2.0*1.42*2.96
|
