Quick Details
-
Jacket:
-
PE
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Winpower
-
Model Number:
-
EN H1Z2Z2-K 35mm2
-
Product name:
-
PV Solar Cable
-
Ambient temperature:
-
-40+90 Degree
-
Rated voltage:
-
600V/1000V AC or 1500v DC
-
Fire test:
-
IEC60332-1
-
Reference standard:
-
EN50618
-
Conductor:
-
Oxygen-free Copper Wire
-
Insulation:
-
XLPO Insulation
-
Usage:
-
Photovoltaic System
-
Packing:
-
Rolls
-
Cross section:
-
1.5mm2/2.5mm2/4mm2/6mm2/10mm2/25mm2/35mm2
Quick Details
-
Insulation Material:
-
Xlpe
-
Application:
-
Power Station
-
Conductor Material:
-
Copper
-
Jacket:
-
PE
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Winpower
-
Model Number:
-
EN H1Z2Z2-K 35mm2
-
Product name:
-
PV Solar Cable
-
Ambient temperature:
-
-40+90 Degree
-
Rated voltage:
-
600V/1000V AC or 1500v DC
-
Fire test:
-
IEC60332-1
-
Reference standard:
-
EN50618
-
Conductor:
-
Oxygen-free Copper Wire
-
Insulation:
-
XLPO Insulation
-
Usage:
-
Photovoltaic System
-
Packing:
-
Rolls
-
Cross section:
-
1.5mm2/2.5mm2/4mm2/6mm2/10mm2/25mm2/35mm2
ENH1Z2Z2-K 35mm2 XLPE jacket copper solar cable
TUV Rehinland EN50618
Rated temperature; -40 Degree to +90 Degree
Voltage test on complete cable :6.5KV AC ,15KV DC ,5min
Max temperature at conductor: +120 Degree
the expected period of use is 25 years (Ambiet temperature -40+90Degree)
the permitted short-circuit-temperature refer to the period of 5s is +200 Degree
Bending radius : ≥4*Φ(D<8mm)≥6*Φ(D≥8MM)
Resistance against acid and alkaline solution : EN 60811-2-1
Cold bending test : EN60811-1-4
Ozone resistance at complete cable : EN50396
Fire test : IEC 60332-1-2
| Cross Section |
Conductor Construction |
Conductor Stranded O.D (MM) |
Number |
Insulation I.D.(mm) |
Jacket OD.(mm) | Conductor MAX Resistance |
| 1.5 | 30/0.25 | 1.58mm | 2C | 2.9 | 4.5*9.0 | 13.7 |
| 2.5 |
49/0.25 |
2.02mm | 2C | 3.4 | 5.0*10.0 | 8.21 |
| 4.0 | 56/0.30 | 2.60mm | 2C | 3.9 | 5.5*11.0 | 5.09 |
| 6.0 | 84/0.30 | 3.42mm | 2C | 4.7 | 6.5*13.0 | 3.39 |
| 10.0 | 84/0.40 | 4.56mm | 2C | 6.2 | 8.0*16.0 | 1.95 |
