Quick Details
-
Color Rendering Index(Ra):
-
82
-
Lifespan (hours):
-
74,000
-
Working Time (hours):
-
74,000
-
Product Weight（kg）:
-
1
-
CRI (Ra>):
-
80
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
A9-2FT20-MMK-E
-
Brand Name:
-
Fanxstar
-
Working Lifetime(Hour):
-
74,000
-
Lamp Luminous Flux(lm):
-
2970lm±5%
-
Application:
-
Garage, Storage area, Workbench, Basement, Home, Office
-
Product Name:
-
Led Linear Light ip66
-
Installation:
-
Surface ceiling /wall /suspend mounting
-
LED Light Source:
-
Lumileds 2835SMD
-
Wattage:
-
20W
-
Emergency Wattage:
-
2W
-
Emergency Duration:
-
3HOURS
-
CCT:
-
3000~65000K (Optional)
-
Lenght:
-
L600xW83xH72mm
-
Size:
-
2ft 0.6m
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
120lm/w
-
IP Rating:
-
IP66
-
Warranty(Year):
-
5 Years Warranty
-
Color Rendering Index(Ra):
-
82
-
Lifespan (hours):
-
74,000
-
Working Time (hours):
-
74,000
-
Product Weight（kg）:
-
1
-
CRI (Ra>):
-
80
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
A9-2FT20-MMK-E
-
Brand Name:
-
Fanxstar
-
Working Lifetime(Hour):
-
74,000
-
Lamp Luminous Flux(lm):
-
2970lm±5%
-
Application:
-
Garage, Storage area, Workbench, Basement, Home, Office
-
Product Name:
-
Led Linear Light ip66
-
Installation:
-
Surface ceiling /wall /suspend mounting
-
LED Light Source:
-
Lumileds 2835SMD
-
Wattage:
-
20W
-
Emergency Wattage:
-
2W
-
Emergency Duration:
-
3HOURS
-
CCT:
-
3000~65000K (Optional)
-
Lenght:
-
L600xW83xH72mm
-
Size:
-
2ft 0.6m
IP66 Full PC 0.6m 20W Led Tri proof Linkable Light Waterproof Led Emergency Batten Light Vapor Tight Fxitures 2W 3hours
Details:
FANXSTAR LED Tri proof l ight Trilamp A 9 Specification
|
Item |
Part Number |
A9-2FT20-MMK- E |
A9-4FT40-MMK-E |
|
|
Description |
Driver & Emergency Converter 2-in-1 Waterproof Emergency Batten |
|||
|
Working |
Mode of Operation |
Maintained |
||
|
Input |
Voltage&Frequency |
220-240Vac, 50/60Hz |
||
|
Wiring Connection |
923 terminal blocks, Loop in and Loop out |
|||
|
Output |
Light Sour ce |
High lumens SMD2835 |
||
|
Color Temperature |
MM=27-65 stands for 2700-6500K |
|||
|
Luminous Flux |
1 4 0lm/w±10% |
|||
|
Power Consumption |
20W |
40W |
||
|
Controls |
Protection |
Overcharge, low voltage disconnect, overcurrent, short circuit |
||
|
Multimode |
Standy, Microwave Sensor and Emergency |
|||
|
Emergency |
Charger |
16hr intelligent 3-stage charger with battery management system |
||
|
Emergency Power |
2W |
3W |
||
|
Duration Time |
3 hours |
3 hours |
||
|
Testing Facility |
Manual test, Self test |
|||
|
Indicators |
Battery charger green LED, Function failure through red LED. |
|||
|
Physical |
Construction |
Diffuser - high transmission opal polycarbonate, chassis - polycarbonate |
||
|
Mou n ting |
Surface mounted - ceiling / wall |
|||
|
Colour |
Gray RAL7035 |
|||
|
Dimensions L x W x H(mm) |
600x83x72 |
600x83x72 |
||
|
IP/IK Rating |
IP66 & IK10 |
|||
|
Weight |
1.0kg |
2.0kg |
||
|
Warranty |
5 years on product, 3 years on battery |
|||
|
Environment |
Operating Temperature |
-20° to 50°C |
||
|
Relative Humidity |
-10 to 95% |
|||
|
Compliance |
Standards |
CE/UKCA/RCM, EN1838, IEC60598.1, AS/NZS 2293 |
||
|
AS/NZS 2293 Classification |
C0 D63, C90 D40 |
|||
|
Accessories |
Microwave Dimming Sensor |
P/N: A9S: FS010ER |
||
|
Replacement Battery |
P/N: A9E: LiFePO4 6.4V 1600/2000mA |
|||
