Quick Details
-
Model Number:
-
Hydraulic Hose 2SN
-
Name:
-
Steel Wire Braid Hydraulic Hose
-
Cover:
-
Oil and environment resistant synthetic rubber
-
Inner tube:
-
oil resistant synthetic nitrile rubber
-
Size:
-
3/16" - 2"
-
Working pressure:
-
40bar~445bar
-
Color:
-
Black or colorized
-
Reinforcement:
-
High Tensile Steel Wire braided
-
Standard:
-
SAE100RAT- DIN/EN853
-
Working Temperature:
-
-40℃~100℃
-
Surface:
-
cloth surface or smooth surface
Quick Details
-
Processing Service:
-
Cutting
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Huntpowr or OEM
-
Model Number:
-
Hydraulic Hose 2SN
-
Name:
-
Steel Wire Braid Hydraulic Hose
-
Cover:
-
Oil and environment resistant synthetic rubber
-
Inner tube:
-
oil resistant synthetic nitrile rubber
-
Size:
-
3/16" - 2"
-
Working pressure:
-
40bar~445bar
-
Color:
-
Black or colorized
-
Reinforcement:
-
High Tensile Steel Wire braided
-
Standard:
-
SAE100RAT- DIN/EN853
-
Working Temperature:
-
-40℃~100℃
-
Surface:
-
cloth surface or smooth surface
1.Construction of SAE 100 R2AT - EN853 2SN
-Tube: oil resistant synthetic rubber.
-Reinforcement: two high tensile steel braid.
-Cover compound : abrasion, ozone and hydrocarbon resistant synthetic rubber.
2.Constant operation : -40 °C +100 °C (-40 °F +212 °F)
air max T
= +70 °C (+160 °F)
Safety factor
: 1:4
3. Color available: black, grey, blue, yellow, red, etc
4. Surface: smooth & cloth
5.Application: high pressure hydraulic lines, fuel oil, antifreeze solutions, air and water.
Related Products
| Hydraulic Hose | Reinforcement | Product Name |
| One steel wire braided | SAE R1AT/DIN 1SN,SAE R1AT/DIN 1ST,DIN 1SNK,DIN/EN 1SN WG,DIN 1SC , SAE R4 , SAE 100R17 | |
| Two steel wire braided | SAE R2AT/DIN 2SN,SAE R2AT/DIN 2ST,DIN 2SNK,DIN 2SC | |
| One/two wire braided | SAE R16 | |
| Four steel wire spiral | SAE R9AT,SAE R10,SAE R12,DIN 4SP,DIN 4SH | |
| Four/six wire spiral | SAE R13,SAE R15 | |
| Textile fiber braided | SAE R3 , SAE R5 , SAE R6 , DIN 2TE | |
| High flexibility nylon or thermoplastic | SAE R7,SAE R8 | |
| Industrial Hose | Steam hose , Water/ Air hose , Fuel/Oil hose , Washer hose | |
