Quick Details
-
Range of Spindle Speed(r.p.m):
-
1 - 8000
-
Spindle Taper:
-
BT40
-
Positioning Accuracy (mm):
-
0.005
-
Repeatability (X/Y/Z) (mm):
-
0.003
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
BLIN
-
Model Number:
-
BL-V7
-
Table Travel (mm):
-
600*400*480
-
Year:
-
2023
-
Voltage:
-
380V/220V/415
-
Dimension(L*W*H):
-
2220*2000*2160mm
-
Weight (KG):
-
3200
-
Spindle Motor Power(kW):
-
5.5
-
Max. Table Load(kg):
-
300 kg
-
CNC or Not:
-
CNC
-
Spindle type:
-
BT40
-
Spindle motor:
-
5.5kw
-
Spindle speed:
-
8000(opt.:10000 belt-drive/12000 direct-drive)
-
Cutting feed speed:
-
10m/min
-
X/Y/Z axes rapid moving speed:
-
36/36/30m/min
-
X/Y/Z axes feeding motor:
-
6/6/11(SIEMENS 808D ADVANCED)
-
Tool magazine type:
-
Arm type 16T
-
Max. tool dia.(fully loaded):
-
80mm
-
Max. tool dia.(no adjacent tool):
-
150mm
Quick Details
-
Table Travel (X) (mm):
-
720 mm
-
Table Travel (Y) (mm):
-
450 mm
-
Table Travel (Z) (mm):
-
470 mm
-
Range of Spindle Speed(r.p.m):
-
1 - 8000
-
Spindle Taper:
-
BT40
-
Positioning Accuracy (mm):
-
0.005
-
Repeatability (X/Y/Z) (mm):
-
0.003
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
BLIN
-
Model Number:
-
BL-V7
-
Table Travel (mm):
-
600*400*480
-
Year:
-
2023
-
Voltage:
-
380V/220V/415
-
Dimension(L*W*H):
-
2220*2000*2160mm
-
Weight (KG):
-
3200
-
Spindle Motor Power(kW):
-
5.5
-
Max. Table Load(kg):
-
300 kg
-
CNC or Not:
-
CNC
-
Spindle type:
-
BT40
-
Spindle motor:
-
5.5kw
-
Spindle speed:
-
8000(opt.:10000 belt-drive/12000 direct-drive)
-
Cutting feed speed:
-
10m/min
-
X/Y/Z axes rapid moving speed:
-
36/36/30m/min
-
X/Y/Z axes feeding motor:
-
6/6/11(SIEMENS 808D ADVANCED)
-
Tool magazine type:
-
Arm type 16T
-
Max. tool dia.(fully loaded):
-
80mm
-
Max. tool dia.(no adjacent tool):
-
150mm
|
Suitable for medium-sized cutting
|
|
|
|
|
||||
|
3 axes adopt high precision linear guideway
|
|
|
|
|
||||
|
Designed by GERMAN engineer
|
|
|
|
|
||||
|
Whole production process accord to TAIWANESE standard
|
|
|
|
|
||||
|
Chips outlet set at back of machine
|
|
|
|
|
||||
|
Most parts adopt GERMAN/JAPANESE/TAIWANESE brand
|
|
|
|
|
||||
|
High speed, high precision, long using lifespan
|
|
|
|
|
||||
|
Adopt HT300 high class cast iron,after aging treatment and FEA analysis
|
|
|
|
|
||||
|
Bridge shape column, high rigidity, high stability
|
|
|
|
|
||||
|
3 axes use C3 class precision ball screw, match up nut preloading and ball screw pre-stretching, pre-eliminate backlash
and temperature rising, ensure stable positioning and repeatable positioning precision |
|
|
|
|
||||
|
Item
|
Specification
|
Unit
|
BL-V7
|
|
Worktable
|
Table size
|
mm
|
900×400
|
|
|
Table max. loading
|
kg
|
300
|
|
|
T slot(NO./width/gap)
|
mm
|
3/14/100
|
|
Travel
|
X/Y/Z axes
|
mm
|
720/450/470
|
|
Spindle
|
Distance from spindle nose to table surface
|
mm
|
120~590
|
|
|
Distance from spindle center to column surface
|
mm
|
440
|
|
|
Spindle type
|
mm
|
BT40/Φ120
|
|
|
Spindle motor
|
kw
|
5.5
|
|
|
Spindle speed
|
rpm
|
8000(opt.:10000 belt-drive/12000 direct-drive)
|
|
Feeding axes
|
Cutting feed speed
|
m/min
|
10
|
|
|
X/Y/Z axes rapid moving speed
|
m/min
|
36/36/30
|
|
|
X/Y/Z axes feeding motor
|
Nm
|
6/6/11(SIEMENS 808D ADVANCED)
|
|
|
X/Y/Z axes ball screw dia./pitch
|
mm
|
32/16
|
|
|
X/Y/Z axes linear guideway width
|
mm
|
30/30/30
|
|
Precision
|
Positioning precision
|
mm
|
±0.005
|
|
|
Repeatable positioning precision
|
mm
|
±0.003
|
|
Tool magazine
|
Tool magazine type
|
/
|
Arm type 16T
|
|
|
Max. tool weight
|
kg
|
8
|
|
|
Max. tool length
|
mm
|
200
|
|
|
Max. tool dia.
|
mm
|
Φ80
|
|
|
Max. tool dia.(no adjacent tool)
|
mm
|
Φ150
|
|
|
Tool changing time
|
/
|
Tool to tool: 1.8s
|
|
Others
|
Overall dimension(L×W×H)
|
mm
|
2220×2000×2160
|
|
|
Weight
|
kg
|
3200
|
