- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Base
-
Number:
-
PA66
-
Color:
-
Customized
-
Model Number:
-
A6103G
-
Filler:
-
(15%-45%)gf
-
Speciality:
-
reinforced/ fire retardant/modified
-
Resin:
-
nylon pa66 gf30/polyamide
-
Type:
-
polyamide Plastics
-
Other name:
-
polyamide with glass fiber
-
Material:
-
Polyamide Nylon PA66 Resin
-
Sample:
-
free
Quick Details
-
color:
-
nature
-
Shape:
-
granules
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Base
-
Number:
-
PA66
-
Color:
-
Customized
-
Model Number:
-
A6103G
-
Filler:
-
(15%-45%)gf
-
Speciality:
-
reinforced/ fire retardant/modified
-
Resin:
-
nylon pa66 gf30/polyamide
-
Type:
-
polyamide Plastics
-
Other name:
-
polyamide with glass fiber
-
Material:
-
Polyamide Nylon PA66 Resin
-
Sample:
-
free
Product Description
PA66
plastic raw material is translucent, white or black crystalline polymer.
PA66 has a higher melting point among polyamide materials. It is a semi-crystalline-crystalline material. PA66 can also maintain strong strength and rigidity at higher temperatures. PA66 is still hygroscopic after molding, and its degree mainly depends on the composition of the material, wall thickness and environmental conditions. The effect of hygroscopicity on geometric stability must be considered during product design.
FEATURES OF NYLON
1. Excellent mechanical properties. Nylon has high mechanical strength and good toughness.
2. Good self-lubrication and friction resistance. Nylon has good self-lubricating properties and a small friction coefficient, so it has a long service life as a transmission component.
3. Excellent heat resistance. High crystalline nylon such as nylon 46 has a high heat distortion temperature and can be used for a long time at 150°C. After PA66 is reinforced by glass fiber, its heat distortion temperature reaches above 250°C.
4. Excellent electrical insulation properties. Nylon has high volume resistance and high breakdown voltage, and is an excellent electrical and electrical insulation material.
5. Excellent weather resistance.
5. Excellent weather resistance.
6. Water absorption. Nylon has high water absorption, and the saturated water absorption can reach more than 3%. To a certain extent, it affects the dimensional stability of the workpiece.
Specification
|
Property
|
Test Method
|
Typical Value
|
Unit
|
|
Melt Flow Rate
|
ISO 1133 @ 190°C/2.16 kg
|
1.6
|
g/10 min
|
|
Melt Flow Rate
|
ISO 1133 @ 210°C/2.16 kg
|
3.7
|
g/10 min
|
|
Density
|
ISO 1183
|
1.19
|
g/cm3
|
|
Water vapor transmission rate
|
ASTM E96 @ 40°C 90RH
|
1.3
|
|
|
Oxygen transmission rate
|
@ 20°C 0RH
|
0.0059
|
|
|
Oxygen transmission rate
|
@ 20°C 65RH
|
0.0079
|
|
|
Oxygen transmission rate
|
@ 20°C 85RH
|
0.03
|
|
|
Tensile Strength at Break
|
ISO 527 @ 23°C
|
34
|
MPa
|
|
Tensile modulus
|
ISO 527 @ 23°C
|
2700
|
MPa
|
|
Elongation at Break
|
ISO 527 @ 23°C
|
15
|
%
|
|
Flexural modulus
|
ISO 178 @ 23°C
|
4800
|
MPa
|
|
Simply Supported Beam Unnotched Impact
|
ISO 179
|
2
|
Kj/m2
|
|
Hardness
|
ISO 2023
|
90
|
|
|
Crystallization temperature
|
ISO 11357
|
158
|
|
|
Glass transition temperature
|
ISO 11357
|
57
|
℃
|
|
Melting temperature
|
ISO 11357
|
183
|
℃
|
