- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ZGSM
-
Model Number:
-
ZGSM-ST19-100M
-
Beam Angle(°):
-
2S, 3S, 2M, 3M
-
CRI (Ra>):
-
70
-
Input Voltage(V):
-
AC 100-240V /277V
-
Lamp Luminous Efficiency(lm/w):
-
145
-
Lamp Luminous Flux(lm):
-
14500
-
Working Temperature(℃):
-
-40 ~ +50
-
Lifespan (hours):
-
100000
-
Product Weight（kg）:
-
6
-
Product name:
-
Led Street Lamp
-
Power:
-
30W/50W/60W/80W/100W/120W/150W/180W/200W
-
Keyword:
-
Led Street Light Head
-
Material:
-
Die-casting Aluminum
-
Color:
-
Gray
-
LED Chip:
-
SMD 3030 LUMILEDS
-
Function:
-
Light Sensor + Remote Control
Quick Details
-
Color Temperature(CCT):
-
2700-6500K
-
Warranty(Year):
-
5-Year
-
Lighting solutions service:
-
Lighting and circuitry design, DIALux evo layout, auto CAD layout
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ZGSM
-
Model Number:
-
ZGSM-ST19-100M
-
Beam Angle(°):
-
2S, 3S, 2M, 3M
-
CRI (Ra>):
-
70
-
Input Voltage(V):
-
AC 100-240V /277V
-
Lamp Luminous Efficiency(lm/w):
-
145
-
Lamp Luminous Flux(lm):
-
14500
-
Working Temperature(℃):
-
-40 ~ +50
-
Lifespan (hours):
-
100000
-
Product Weight（kg）:
-
6
-
Product name:
-
Led Street Lamp
-
Power:
-
30W/50W/60W/80W/100W/120W/150W/180W/200W
-
Keyword:
-
Led Street Light Head
-
Material:
-
Die-casting Aluminum
-
Color:
-
Gray
-
LED Chip:
-
SMD 3030 LUMILEDS
-
Function:
-
Light Sensor + Remote Control
Products Description
Product Parameters
|
Series No
|
Series ST19
|
|
Power
|
30W, 50W, 60W, 80W, 100W,120W, 150W,180W,200W
|
|
Efficacy
|
145-170lm/W
|
|
Input Voltage
|
100-240/277 VAC, 50 / 60 Hz
|
|
Power Factor
|
>0.95
|
|
Surge Protection
|
10KV (Default) / 20KV (available on request)
|
|
IP Rating
|
IP66
|
|
IK Rating
|
IK10
|
|
CCT
|
3000K, 4000K, 5000K, 5700K
|
|
CRI
|
Ra>70 (Default) / Ra>80
|
|
Operating Temperature
|
-40°C to + 50°C
|
|
Beam Angle
|
Type II, Type III, Asymmetric for pedestrian crossings
|
|
Mounting Option
|
Side entry or Vertical pole mounted
|
|
Warranty
|
5 Years
|
|
Certification
|
CE, RoHS, ENEC, CB, LM79, LM80, TM-21, IP66, IK10, IEC62471, IEC60068-2-6, IEC61643-11
|
|
Control
|
NEMA socket (3/5/7pins), ZHAGA socket, Short cap, Photocell, Motion sensor, Knife switch, NTC, OLC, Solar Compatible, DALI Dimming
|
Application
