Auto-CPR device with cpr board (no CPR manikins)

Auto-CPR device with cpr board (no CPR manikins)

FOB Reference Price: Get Latest Price

≥1 Pieces

US $4800

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Function:: Emergency Care

Size:: Size

Name:: CPR

Quick Details

Brand Name:: Medsonic

Model Number:: MSCPR-1A

Place of Origin:: Henan, China

Function:: Emergency Care

Size:: Size

Name:: CPR

Product Description

Working principle

Designed by the requirements of International Cardio Pulmonary Resuscitation (CPR) and Emergency Cardiovascular Care (ECC) Guidelines, and motivated by the pressure of high pressure air (oxygen, air), according to the clinical required compression frequency, press depth and press ventilation ratio, Su Bang digital and multi-functional cardiopulmonary resuscitator is controlled by the digital program control system to achieve accurate chest compressions and pulmonary resuscitation ventilation, provides the sustainable and optimal cardiopulmonary resuscitation support for the patients with cardiac and respiratory arrest, through promoting the heart and lung blood circulation to maintain and restore the body's basic vital signs.

Applications and scope
Su Bang digital and multi-functional cardiopulmonary resuscitator mainly applies to the first aid to the people suffering from the heartbeat and respiratory emergence. It is most suitable for the cardiopulmonary resuscitation happening the rescue on spot and transit on the way (even on the stretcher), but also suitable for all medical emergency systems, ambulance, rescue aircraft, emergency room, coronary heart disease care room, cardiac catheterization room, CCU ward, ICU ward, etc..

Contraindication
Infants, children, osteoporosis, breast and chest fractures or with fractures history are disabled.

intelligence： Key-press operation.

Technical parameters

a) Input power: DC: ≤17W; AC: ≤54W;

b) Ventilation quanity: 350ml~900ml continuously adjustable,

c) Pressing depth: 30mm~70mm continuously adjustable, each adjustment 5mm;

d)Pressing frequency: 80 times/minute, 90 times/minute, 100 times/minute, 110 times/minute, 120 times/minute continuously adjustable;

e)with a separate continuous ventilation function, ventilation frequency 8 times/minute, 10 times/minute, 12 times/minute, 14 times/minute, 16 times/minute continuously adjustable;

f) Press the ventilation ratio: 30: 2,15: 2, separete continuously press three operation modes

can be switched;

g) vertical adjustment height: minimum 155mm, maxium 315mm;

h) external dimensions:

the main machine size: 660mm x566mm x（526.5~686.5）mm

resuscitation plate size：485mm x460mm x56mm

Detailed Images

Accurate

Compression Depth: error≤ 2mm

Compression Frequency: error= 0

Safety: The specifical safety condition when start up the CPR. Open type, vertical press and rotating arms

Convenience

1. Air access equipped with fast plug-in;

2.Quick start in 2 senconds.

3. 360º free rotation, either side of CPR board could insert or get out, Convenient cooperate with defibrillation and other rescue measures.

Packing & Delivery

Packing: Carton, Standard export packing ,The following picture is our inner packing for the product. and when ship there are outer carton packing.
Delivery way： A small order Can ship by DHL, FEDEX TNT etc. Larger order can be shipped by air or sea.
Delivery time：3-5days after payment
