200~850V to 48V dc generator 48V battery charger 5kw 10kw uav drone 48v isolated dc-dc converter 3kw mppt controller 100a 48v

200~850V to 48V dc generator 48V battery charger 5kw 10kw uav drone 48v isolated dc-dc converter 3kw mppt controller 100a 48v

FOB Reference Price: Get Latest Price

≥5 Pieces

US $728

≥10 Pieces

US $698

≥100 Pieces

US $548

≥500 Pieces

US $498

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Model Number:: 3Kw/4.5Kw/5kw/6kw/20kw DCDC

Output Frequency:: 50Hz/60Hz

Size:: According to power

Weight:: According to power

Product name:: EV DCDC Converter 5kw 6kw 10kw 20kw 48V

Input voltage range:: 200~850Vdc

Efficiency:: 96%

Output voltage:: 48Vdc/54Vdc/27.5V/57.6V

Warranty:: 3 Years

Certificate:: CE ROHS

Quick Details

Output Current:: According to power

Place of Origin:: Fujian, China

Brand Name:: YSTECH

Model Number:: 3Kw/4.5Kw/5kw/6kw/20kw DCDC

Output Frequency:: 50Hz/60Hz

Size:: According to power

Weight:: According to power

Product name:: EV DCDC Converter 5kw 6kw 10kw 20kw 48V

Input voltage range:: 200~850Vdc

Efficiency:: 96%

Output voltage:: 48Vdc/54Vdc/27.5V/57.6V

Warranty:: 3 Years

Certificate:: CE ROHS

Product Description

About This Item ：

Product features:Small size, light weight, high conversion efficiency, Suitable for new energy vehicles 380V, 540V or 640Vdc high-voltage platform to low-voltage 48Vdc,54Vdc,27.5V(24V) for DC supply devices or for battery pack charging. This 48V 5kw DCDC module Supporting multiple modules to expand power in parallel to charge the battery pack or for DC loader

This series of DCDC products, 600w, 800w, 1kw, 1.5kw,2kw,2.5w,3kW,3.3kw,3.5kw,4kw, 5kw, 6kw,20kw optional,
Input voltage:200~850Vdc; O utput: 48Vdc/54Vdc/57.6V/13.8V/27.5Vdc/ Customized

Waking up the DCDC to start or stop working through CAN communication or high and low logic level, Or even as long as there is a high voltage input, there will be a low voltage output (default mode)

More features include：
⚡ 95% High Conversion efficiency
⚡ 200~850Vdc to 48Vdc / 54Vdc / 57.6V/ 27.5V / Customized
⚡ 3kw 3.3kw,4.5kw,5Kw,10Kw Output Power optional

⚡ Support multiple modules in parallel using
⚡ 100% Stable voltage output
⚡ 100% full real power
⚡ Support CAN Bus / High and low logic level signal control
⚡ Comprehensive Protection

⚡ Cooling method ： Natural cooling/ Air cooling/ Liquid cooling / Modular optional

⚡ 5000w 200~850V to 48V/54V/27.5V (42-60V adjustable) ——
Input Voltage: 200-850Vdc
Output current: 92A
Output Voltage: 54V/48V/27.5V/57.6V ( customizable )
Output Power: 5000w( Support module parallel expansion power )

Peak power: 5500w Continued for 6 minutes
Conversion efficiency: 96%
Control method: CAN Bus enable/ Logic 9~32V high logic level or low logic enalbe/power on output/ customizable

⚡ 6000W 260~850V to 48V(20-60V adjustable) —— Liquid cooling
Input Voltage: 260-750Vdc
Output current: 150A
Output Voltage: 48V/57.6V/ Customized
Output Power: 9000w
Conversion efficiency: 95%
Control method: CAN Bus / Logic 12V high and low level

⚡ 1.2Kw 200~850V to 13.8V ——
Input Voltage: 200-850Vdc
Output current: 90A
Output Voltage: 13.8V
Output Power: 1200w
Conversion efficiency: 91%
Control method: CAN Bus / Logic 12V high and low level

⚡ 1.5Kw 200~850V to 13.8V ——
Input Voltage: 200-750Vdc
Output current: 108A
Output Voltage: 13.8V
Output Power: 1500w
Conversion efficiency: 95%
Control method: CAN Bus / Logic 12V high and low level

⚡ 2.0Kw DCDC 200~850V to 13.8V/27.5V ——
Input Voltage: 200-750Vdc
Output current: 145A@ 13.8V
Output current: 73A@ 27.5V
Output Voltage: 13.8V/27.5V
Output Power: 2000w
Conversion efficiency: 95%
Control method: CAN Bus / Logic 12V/24 high and low level

⚡ 2.5Kw DCDC 200~850V to 27.5V ——
Input Voltage: 200-850Vdc
Output current: 91A
Output Voltage: 27.5V
Output Power: 2500w
Conversion efficiency: 95%
Control method: CAN Bus / Logic 24V high and low level

⚡ 3Kw DCDC 200~850V to 27.5V ——
Input Voltage: 200-850Vdc
Output current: 109A
Output Voltage: 27.5V
Output Power: 3000w
Conversion efficiency: 95%
Control method: CAN Bus / Logic 24V high and low level

⚡ 4.5Kw DCDC 200~850V to 27.5V ——
Input Voltage: 200-750Vdc
Output current: 163A
Output Voltage: 27.5V
Output Power: 4500w
Conversion efficiency: 95%
Control method: CAN Bus / Logic 24V high and low level

⚡ OEM and ODM Services — Yes, we can provide products according to customer requirements.We can provide professional product design, development, production and processing services.if you need any customization requirements please contact us or Leave us a message , We will do our best to provide provide professional OEM/ODM services for you.

ECU or BMS DCDC Power Supply.(300w, 600w, 800w, 1000w Optional)

On board ECU or BMS DCDC Power Supply Provide long-term uninterrupted power supply for ECU or BMS

On board ECU or BMS DCDC Power Supply （300W, 600W, 800W, 1000W Optional）

On board ECU DCDC power supply provides long-term uninterrupted power supply for DC equipment, and provides stable and reliable uninterrupted power supply for vehicle controllers or other high-voltage to low-voltage monitoring equipment .

Why Us

We are a professional manufacturer. Our DCDC products are mainly used in EV buses, EV cars, EV logistics, etc. Our products have more than 9 years of service experience in the Chinese market and have been fully verified by the market. Most importantly, our products are very stable and reliable, and are well received by our customers.
Our products are designed by excellent engineers, and we have automated production processing, strict and perfect testing system, and 100% factory aging test.

Specification

item	value
Network	Off-grid
Customized support	Software reengineering, Input/output voltage, Socket type
Type	DC/DC Converters
Output Type	DC 54V , DC48V, (13.8V, 27.5V, 12V, 24V optional)
Size	27754161 mm
weight	4KG
Product name	5Kw, 3Kw 3.3Kw 4.5Kw, 9kw 10Kw DCDC
Input voltage range	200V ~850Vdc
Output Voltage	54V/48V/27.5V (13.8V, 27.5V, 12V, 24V optional)
Efficiency	≥95%
Cooling method	Air cooling / Modular/ liquid cooling (optional)
Warranty	3 Years

DCDC Charger Module/DCDC Power Supply.

200-1000V high-voltage to 30-750V DCDC DCDC isolated power supply is widely used in photovoltaic energy storage system power conversion, photovoltaic charging station, and other DC conversion application scenarios. It is characterized by high conversion efficiency, safety, reliability and stability.

Bidirectional DCDC Module/ Bidirectional ACDC Module Power Supply.

200-1000V high voltage to 30-750V bidirectional DCDC, V2G, ACDC bidirectional power supply, bidirectional isolated power module, widely used in photovoltaic energy storage system power conversion, photovoltaic charging station, EV charging station, and other application scenarios requiring bidirectional power conversion, with high conversion efficiency, safe, reliable and stable performance.

EV DC charger module （15Kw, 20Kw, 30Kw 40Kw Optional）

DC charger module has an output of 200-1000vdc and a power of 15kw-30kw. The charger power can be expanded in parallel through the module. Using CAN bus communication control, we can quickly develop chargers suitable for electric vehicles, electric logistics vehicles, electric buses and charging stations, and can develop into portable DC chargers, wall mounted DC chargers or DC chargers for charging stations.

Electric forklift DC charger module（2kW, 3kW, 3.5kw, 6kW, 7.5kw,9kW,10kw 20Kw Optional ）

Electric forklift charger module outputs 40-200vdc/450Vdc and the power is 2kw-10kw. The charger power can be expanded in parallel through the module. Using CAN bus communication control, we can quickly develop chargers suitable for electric forklifts, electric logistics vehicles, electric golf vehicles, electric tricycles, and portable DC chargers or wall mounted DC chargers.
