Quick Details
-
Brand Name:
-
NEJE
-
Weight (KG):
-
0.15 KG
-
Heatsink Material:
-
Aircraft Aluminum + Brass Shell
-
Luminous Color:
-
Blue
-
Laser diode:
-
(The maximum power 5.6mm laser diode)
-
LD Current:
-
1.6A
-
Section Size:
-
30mm x 30mm
-
Dimension:
-
60 * 30 * 30mm
-
Adapter Output Voltage:
-
12V 1A
-
Module Input:
-
10W
-
Wavelength:
-
450nm
-
Beam Shape:
-
Dot (Focusable)
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Spare Parts Type:
-
module
-
Marketing Type:
-
New arriving 2021
-
Brand Name:
-
NEJE
-
Weight (KG):
-
0.15 KG
-
Heatsink Material:
-
Aircraft Aluminum + Brass Shell
-
Luminous Color:
-
Blue
-
Laser diode:
-
(The maximum power 5.6mm laser diode)
-
LD Current:
-
1.6A
-
Section Size:
-
30mm x 30mm
-
Dimension:
-
60 * 30 * 30mm
-
Adapter Output Voltage:
-
12V 1A
-
Module Input:
-
10W
-
Wavelength:
-
450nm
-
Beam Shape:
-
Dot (Focusable)
Related Products
Product Description
Selling points:
1. Warehouse in
Netherlands,Poland,UK,Gemany,Spain,USA,Russia
2. Accept Dropshipping and Delivery in 24 hours
2. Accept Dropshipping and Delivery in 24 hours
3. Factory direct sell
4.Accept OEM/ODM orders
4.Accept OEM/ODM orders
Specification
：
|
Radiator size
|
25x25x40m
|
|
weight
|
56g
|
|
Speed of the Fan
|
10600RPM
|
|
Interface
|
PH2.04Pir
|
|
Drive design
|
Buit-in
|
|
Input
|
12V 1A
|
|
0ptical power
|
2.5W
|
|
Wavelength
|
450nm
|
|
Can Engrave
|
MDF/Balsa/Paper/Wood/Fabric/Plastic/Leather/Plywood/Foam Paper/Anodized Aluminum
|
|
Can Not Engrave
|
Metal/Glass/Stone/Ceramics/PCB/Stainless Steel/Reflective Material/ Transparent Material
|
|
Module Input
|
10W
|
|
Min focus spot size
|
0.03x0.03mm
|
|
Warranty
|
2 years(20000h)
|
|
Beam Shape
|
Dot (Focusable)
|
|
Max cutting&carving deeptth
|
8mm
|
|
TTL&PWM Modulation
|
YES, Compatible with Both TTL & PWM Modulation
|
|
Input Voltage
|
DC12V
|
|
PWM/TTL Input
|
3.3-12V.0-20KHZ
|
|
Input Interface
|
PH2.0-4Pin (+,-, PWM/TTL, Temperature), 3Pin (+,-, PWM/TTL) , 2Pin+2Pin (+,-) + (PWM/TTL,-)
|
1. High optical precision, 0.06mm focus point
2. 10W high power, 2.5W optical power output
3. Wide application, able to engrave black alumina, good at deep engraving
4. Lightweight, high-speed scanning without jitter
5. Intelligent, quiet, intelligent drive design, built-in control program can adjust the fan working state according to the TTL state and laser temperature
6. High heat dissipation performance, 20000 hours life
packing list
* Laser module * 1
* Screw installation kit (5 pcs)*1
* 30cm 4pin laser line * 1
* Interface adapter board * 1
* 2pin TTL signal line * 1
* 3pin input signal cable * 1
* Laser module * 1
* Screw installation kit (5 pcs)*1
* 30cm 4pin laser line * 1
* Interface adapter board * 1
* 2pin TTL signal line * 1
* 3pin input signal cable * 1
