Quick Details
-
Interface Standard:
-
CAN/RS485/UART TTL
-
Output Current:
-
1A≤I≤17A
-
Output Power:
-
1KW
-
Input Voltage:
-
AC85-264V
-
Type:
-
OBC Charger
-
Keyword:
-
Golf carts onboard Lifepo4 Battery Smart Charger
-
Application:
-
Select lithium battery and lead-acid battery by DIP switch
-
Combination:
-
adapted to multi-country input plugs
-
Material:
-
Metal
-
Rated current:
-
17A
-
Power:
-
1KW
-
Charging Standard:
-
Compatible with global voltage input
-
Compatible with:
-
24V, 36V, 48V, 60V 72V 84V battery packs
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
CT8417/SH, CT8417/SH
-
Brand Name:
-
OEM/ODM
-
Interface Standard:
-
CAN/RS485/UART TTL
-
Output Current:
-
1A≤I≤17A
-
Output Power:
-
1KW
-
Input Voltage:
-
AC85-264V
-
Type:
-
OBC Charger
-
Keyword:
-
Golf carts onboard Lifepo4 Battery Smart Charger
-
Application:
-
Select lithium battery and lead-acid battery by DIP switch
-
Combination:
-
adapted to multi-country input plugs
-
Material:
-
Metal
-
Rated current:
-
17A
-
Power:
-
1KW
-
Charging Standard:
-
Compatible with global voltage input
-
Compatible with:
-
24V, 36V, 48V, 60V 72V 84V battery packs
Specification
|
item
|
value
|
|
Product Name
|
Golf Cart Battery Charger
|
|
Output Power
|
1KW
|
|
Product model
|
CT8417/SH
|
|
Input voltage
|
AC85-264V
|
|
Incoming frequency
|
50HZ±10HZ
|
|
Input power factor
|
≥0.98
|
|
Working temperature
|
40℃ ~ + 65℃; -40℃ (± 4℃) module works; Use with over 50℃; shutdown over 65℃.
|
|
Output power
|
1KW
|
|
Output rated current
|
DC 17A
|
|
Output voltage
|
24V-84V
|
|
Current limiting value adjustment range
|
1A≤I≤17A
|
|
USB
|
Various model charging ports can be customized
|
|
Cooling-down method
|
Fanless natural air cooling
|
|
Communication interface
|
CAN/RS485/UART TTL
|
|
Car agreement
|
In-vehicle applications can communicate with the vehicle central control and battery BMS
|
|
Levels of protection
|
≥IP65
|
