Application Functions
Built-in Video MCU, SIP Registrar Server, NAT Traversal Server, Enterprise Collaboration Server, Contacts Manager, Recording/Storage Server, WebRTC Server
Conference Capacity
Up to 120-way 1080p H.264 video/audio MCU
Up to 300 participants (aggregate) with 2-way audio and 1-way 1080p H.264/VP8 video streaming,
supports H.323 gateway
Up to 10 meeting rooms simultaneously
Supports up to 50 meetings of two parties, or 10 meetings of three parties
Video Support
H.264 BP/MP/HP, VP8, and HEVC/H.265 with up to 1080p 30fps resolution and 6Mbps bit rate per stream
Audio Support
Opus, G.722, G.711a/u, up to 48KHz wide-band audio mixing
Network Jitter Resilience
Advanced anti-jitter algorithms to sustain high quality audio/video against up to 30% packet loss
Smart adaptation to dynamically adjust bandwidth between 64Kbps and 6Mbps based on
network condition
Security
Support HTTPS and WSS/DTLS-SRTP encryption for WebRTC, and TLS/SRTP encryption for SIP
Supports static defense settings including Ping Defense, SYN-Flood Defense, Ping-of-Death Defense, and Fail2Ban
Video Display
Support 2x2/3x3/4x4/5x5/6x6/7x7 Tile Video Layout, or 1 Primary + N Secondary (up to 7
secondary) Video Layout
New Features: one meeting can be customized in 3 layouts. WebRTC Host can set different layouts for different participants
Active Speaker Highlight
Automated active speaker detection and highlight
Meeting Management
Support Immediate or Scheduled meetings/Webinars, multiple hosts/panelists, audio/video ON/OFF control
Desktop/application sharing, group or private chat, Q&A, forced attendee Mute/Camera-Off/Exit by host
Customizable content for meeting invitation/registration/reminder/post-meeting reports and follow-up
Customized video screen banner subtitle with customizable display settings
Live Streaming
Support live streaming with Facebook and Youtube, and other live streaming platforms via RTMP push
Supported Devices
Grandstream GVC series video conference systems, GXV series video phones
PC/Mac using WebRTC browsers, Android/iOS based mobile devices using Grandstream IPVideoTalk Mobile app
Audio calling from PSTN SIP trunk or SIP based IPPBX, 3rd party SIP based video conference systems and video phones
Meeting Recording
Support up to 500GB local storage of audio/video/chats recording, meeting reports, etc
Deployment Scalability
Scalable architecture to support multi-server configuration with load-balancing and redundancy for large deployments
Added docking NAS Storage supporting NFS mount feature
Multi-Language
English, German, French, Spanish, Chinese, Japanese, Arabic, etc
Power Supply
Redundant 550W power supplies
Network Interfaces
2x Gigabit network ports, 1x RJ45 IPMI network port
Auxiliary Interfaces
3x USB 3.0 ports, 3x USB 2.0 ports, and 1x VGA port
Physical Dimension
430mm (W) x 650mm (L) x 88mm (H), 2U rack design suitable for 19-inch cabinet and guide rail
|
