Quick Details
-
Size:
-
4650*2800*1800mm
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
YASEN
-
Power:
-
1.5kw
-
Product name:
-
Automatic Linen Folder
-
Model:
-
ZD-3300V
-
Function:
-
Folding Bedsheets
-
Capacity:
-
3300mm
-
Used for:
-
Hotel.factory .laundry Hospital
-
Material:
-
Stainless Steel
-
Certification:
-
CE/OHSAS18001/ISO14001
-
Power Supply:
-
380/3/50 (V/P/Hz)
-
Brand:
-
YASEN
Quick Details
-
Warranty:
-
1 Year
-
After-sales Service Provided:
-
Video technical support, Field installation, commissioning and training, Free spare parts, Online support
-
Weight:
-
2350kg
-
Size:
-
4650*2800*1800mm
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
YASEN
-
Power:
-
1.5kw
-
Product name:
-
Automatic Linen Folder
-
Model:
-
ZD-3300V
-
Function:
-
Folding Bedsheets
-
Capacity:
-
3300mm
-
Used for:
-
Hotel.factory .laundry Hospital
-
Material:
-
Stainless Steel
-
Certification:
-
CE/OHSAS18001/ISO14001
-
Power Supply:
-
380/3/50 (V/P/Hz)
-
Brand:
-
YASEN
Products Description
1.Used for bedsheets, quilts, tablecloth etc., 1 fold to 5 folds, various folding program, meet
different requirements
2.135°rotatable PLC controller, convenient for the workers to operate from different sides
3.Connect with flatwork ironing machine to realize ironing and folding by one workflow,
economize on manpower and increase production greatly
After sales service:
The whole machine has been guaranteed for 1 years.
Providing lifelong technical support.
Guarantee of spare parts supply.
Engineers available to service machinery overseas.Installation and Test
(1)Free technical train at factory
(2)Free technical guide through network
(3)On-site service under contract
Warranty:
Main spare parts(except consumable accessories) under ONE YEAR Warranty with defects from manufacturer by free shipping
different requirements
2.135°rotatable PLC controller, convenient for the workers to operate from different sides
3.Connect with flatwork ironing machine to realize ironing and folding by one workflow,
economize on manpower and increase production greatly
After sales service:
The whole machine has been guaranteed for 1 years.
Providing lifelong technical support.
Guarantee of spare parts supply.
Engineers available to service machinery overseas.Installation and Test
(1)Free technical train at factory
(2)Free technical guide through network
(3)On-site service under contract
Warranty:
Main spare parts(except consumable accessories) under ONE YEAR Warranty with defects from manufacturer by free shipping
Product Parameters
|
|
ZD-3000V
|
ZD-3300V
|
ZD-3000V-4
|
ZD-3300V-4
|
|
Max Feeding Width(mm)
|
3000
|
3300
|
3000
|
3300
|
|
Max Folding(times)
|
5
|
5
|
5
|
5
|
|
Folding Speed(m/min)
|
10-50
|
10-50
|
10-50
|
10-50
|
|
Air Pressure(Mpa)
|
0.65-1.0
|
0.65-1.0
|
0.65-1.0
|
0.65-1.0
|
|
Compressed air(m3/min)
|
0.5
|
0.5
|
0.5
|
0.5
|
|
Compressed air inlet(mm)
|
16
|
16
|
16
|
16
|
|
Motor Power(kw)
|
1.5
|
1.5
|
1.5
|
1.5
|
|
Rated-Voltage(V)
|
3P/220V/380V
|
3P/220V/380V
|
3P/220V/380V
|
3P/220V/380V
|
|
Dimension WxDxH(mm)
|
4350x2800x1800
|
4650x2800x1800
|
4350x2800x1800
|
4650x2800x1800
|
|
N.W.(kg)
|
2200
|
2350
|
2200
|
2350
|
