Quick Details
-
Return Force (kN):
-
110 kN
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
sunglory deep drawing hydraulic press
-
Year:
-
2020
-
Voltage:
-
Customized
-
Dimension(L*W*H):
-
1900*1900*3600
-
Weight (T):
-
1.5 T
-
Model Number:
-
YZ28G-150
-
Motor Power (kw):
-
37 kw
-
CNC or Not:
-
Normal
-
Power Source:
-
Hydraulic
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Power(W):
-
37KW
-
Weight:
-
15T
-
Product name:
-
hydraulic press machine
-
Color:
-
blue
-
Weight (KG):
-
1500
Quick Details
-
Machine Type:
-
Hydraulic pressing machine
-
Slide Stroke (mm):
-
300
-
Ejector Force (kN):
-
30
-
Return Force (kN):
-
110 kN
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
sunglory deep drawing hydraulic press
-
Year:
-
2020
-
Voltage:
-
Customized
-
Dimension(L*W*H):
-
1900*1900*3600
-
Weight (T):
-
1.5 T
-
Model Number:
-
YZ28G-150
-
Motor Power (kw):
-
37 kw
-
CNC or Not:
-
Normal
-
Power Source:
-
Hydraulic
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Power(W):
-
37KW
-
Weight:
-
15T
-
Product name:
-
hydraulic press machine
-
Color:
-
blue
-
Weight (KG):
-
1500
Specification
|
Item
|
|
Unit
|
YZ28G-150
|
|
|
Main Cylinder Force
|
|
KN
|
1000
|
|
|
Rating Working Pressing Of Hydraulic System
|
|
Mpa
|
20
|
|
|
Return Force
|
|
KN
|
110
|
|
|
Cushion Force
|
|
KN
|
500
|
|
|
Max. Working Pressure Of Cushion Cylinder
|
|
Mpa
|
20
|
|
|
Ejector Force
|
|
KN
|
30
|
|
|
Max. Stroke Of Cushion Cylinder
|
|
MM
|
250
|
|
|
Max. Stroke Of Ejector
|
|
MM
|
200
|
|
|
Max. Stroke Of Slide Table
|
|
MM
|
540
|
|
|
Open Height
|
Max.
|
MM
|
940
|
|
|
|
Min.
|
MM
|
400
|
|
|
Slide Speed
|
Down
|
MM/S
|
330
|
|
|
|
Pressure
|
MM/S
|
19-38
|
|
|
|
Up
|
MM/S
|
300
|
|
|
Cushion Speed
|
Up
|
MM/S
|
110
|
|
|
|
Down
|
MM/S
|
Down with slide table
|
|
|
Power Of Motor
|
|
KW
|
18.5
|
|
|
Dimension Of Working Table
|
|
MM ²
|
650*750
|
|
|
Dimension Of Machine(LR*FB*H
|
|
MM ²
|
1900*1900*3600
|
|
