Quick Details
-
Size:
-
13500mm*2500mm*3800mm
-
Place of Origin:
-
China
-
Voltage:
-
24 Volt
-
Payload:
-
40ton
-
Air tank:
-
45L, 2 pcs, China
-
Dimension:
-
13500mm*2500mm*3800mm
-
Emergency relay valve:
-
Wabco relay valve
-
Mud guard:
-
Steel mud guard
-
Rim:
-
9.00*22.5 steel disc wheel, 10 holes ISO, 12 pcs. China
-
Axle:
-
3 axles
-
Landing gear:
-
28 ton two speed telescopic manual landing gear
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
40ton
-
Brand Name:
-
Yuetong
-
Size:
-
13500mm*2500mm*3800mm
-
Place of Origin:
-
China
-
Voltage:
-
24 Volt
-
Payload:
-
40ton
-
Air tank:
-
45L, 2 pcs, China
-
Dimension:
-
13500mm*2500mm*3800mm
-
Emergency relay valve:
-
Wabco relay valve
-
Mud guard:
-
Steel mud guard
-
Rim:
-
9.00*22.5 steel disc wheel, 10 holes ISO, 12 pcs. China
-
Axle:
-
3 axles
-
Landing gear:
-
28 ton two speed telescopic manual landing gear
Products Description
|
Yuetong Automobile Industry (Tianjin) Co.,Ltd.
|
|
|
|
Model number
|
LYT9400XXY
|
|
|
Outer Dimension
|
13500mm*2500mm*3800mm
|
|
|
Tare weight
|
9500kg
|
|
|
Air tank
|
45L, 2 pcs, China
|
|
|
Side wall
|
Steel corrugated wall plate 1.2 mm thickness,height 2000mm
|
|
|
Chassis
|
|
|
|
Main beams
|
Material Q345 high strengthen steel. Fabricated “H” beam height 500mm, Top flange thickness 14mm, Middle web thickness 6mm, Bottom flange thickness 16mm
|
|
|
Axle
|
FUWA axle, 3pcs*13 ton capacity, Made in China
|
|
|
Landing gear
|
28 ton two speed telescopic manual landing gear
|
|
|
King Pin
|
3.5” Kingpin, bolted in type
|
|
|
Suspension
|
Mechanical suspension on 3 axles, with leaf spring 10 pcs*90mm*13mm
|
|
|
Brake chamber
|
6 units T30/30 spring brake chambers
|
|
|
Brake System
|
Dual line pneumatic brake, with hose and connector
|
|
|
Rim
|
9.00*22.5 steel disc wheel, 10 holes ISO, 12 pcs. China
|
|
|
Tire
|
Triangle brand, 12R22.5, 12 pcs. China
|
|
|
Turn signal lamp
|
Amber
|
|
|
Valve
|
Wabco relay valve
|
|
|
Electrical system
|
Voltage: 24 Volt
Receptacle: 7 way socket standard, China Front lamp: White Side marker lamp: White & Red |
|
|
Tool box
|
1 pc
|
|
|
Painting
|
Sand blasting before painting; one coats of primer, anti-corrosion; two coat of finish painting; color advised by client.
|
|
|
Transport
|
By Bulk Cargo, RORO
|
|
