Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CUMMINS
-
Model Number:
-
VCM-30TKA184G
-
Speed:
-
1500rpm/1800rpm
-
Weight:
-
1150
-
Engine Model:
-
Cummins 4BT3.9-G1
-
Generator Type:
-
Silent/Open/Trailer
-
Engine type:
-
Water cooled, 4 Cylinder in line, 4 stroke, Turbo charged
-
Bore*stroke(mm):
-
102*120
-
Alternator brand:
-
Stamford/ Marathon/ Leroysomer
-
Alternator model and type:
-
CP-184G, brushless, all copper
-
Control Panel:
-
Deepsea / ComAp / Smartgen
-
Fuel Consumption(g/kw.h):
-
229g/kw h
-
Noise level:
-
65-68dBA@7m
-
Displacement:
-
60L
Quick Details
-
Rated Voltage:
-
12V, 48V, 110V, 220V, 230V, 240V, 380v, 400V, 480V, 127V 220V 230V 240V 380V 400V
-
Rated Current:
-
47.6A
-
Frequency:
-
50Hz/60Hz
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CUMMINS
-
Model Number:
-
VCM-30TKA184G
-
Speed:
-
1500rpm/1800rpm
-
Weight:
-
1150
-
Engine Model:
-
Cummins 4BT3.9-G1
-
Generator Type:
-
Silent/Open/Trailer
-
Engine type:
-
Water cooled, 4 Cylinder in line, 4 stroke, Turbo charged
-
Bore*stroke(mm):
-
102*120
-
Alternator brand:
-
Stamford/ Marathon/ Leroysomer
-
Alternator model and type:
-
CP-184G, brushless, all copper
-
Control Panel:
-
Deepsea / ComAp / Smartgen
-
Fuel Consumption(g/kw.h):
-
229g/kw h
-
Noise level:
-
65-68dBA@7m
-
Displacement:
-
60L
| Diesel Generator Data Sheet | |
| Generator Model | VLAIS-C31.3 |
| Rated Power | 25KW/31.3KVA |
| Rated Voltage | 220V/380V(Voltage can be customized) |
| Frequency | 50HZ |
| Power Factor | COS=0.8 |
| Weight(kg) | 870KG |
| Cooling Method | Water-cooled |
| Start-up Mode | DC 12V/Electric Start |
| ATS | Can be retrofitted additionally |
| Diesel Engine Data Sheet | |
| Brand | Cummins |
| Model | 4BT3.9-G1 |
| Number of Cylinder | 4 Cylinder Vertical in Line |
| Speed | 1500RPM(50hz) |
| Cycle | 4 Stroke |
| Aspiration | Turbo charged |
| Cooling Method | Water-cooling |
| Bore*Stroke(mm) | 102*120 |
| Compression Ratio | 17.3:1 |
| Speed Governor | Electronic |
| Fuel Consumption | 0.26L/kw h |
| Fuel Tank | 8-10 Running Time(can be customized) |
| Alternator Data Sheet | |
| Brand | Stamford/ Marathon/ Leroysomer |
| Model | CP-184G |
| Connecting Type | Single Phase/Three Phase and Four Wires |
| Exciter Type |
Single bearing, brushless, self-excited |
| Protection Grade | IP23 |
| Insulation Class | H |
| Exciter Type | Brushless, Self-excited, AVR Controller |
| Altitude | ≤1000m |
| Controller | |
| Optional Controller Brand | Mebay(Can be upgraded to Deepsea/ComAp/Smartgen) |
· Warranty
12 months or 1000 running hours from shipment date. If the quality problem arise during the warranty period,and
verified the problem is caused by our genset-body instead of external or natural reasons. (Refer to all kinds of
natural disaster, shipping, loading, unloading, wrong-operation, etc),we will supply the relevant spare parts free of
charge for maintenance;after the warranty period, we can supply the required spare parts for you under cost prices .
