- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
TUOERPU
-
Certificate::
-
iso 9001 :2008 , CE approved actuator
-
Ball Rotation Angle::
-
90°
-
Color:
-
Blue ,Orange etc
-
Torque:
-
50~2000N.m
-
Time:
-
4~50s
-
Voltage:
-
12~440V
-
Protection Level:
-
IP65 (Optional :IP67/IP68)
-
Input/output signal:
-
4-20mA 0-10VDC
Quick Details
-
Port Size:
-
Reference page
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
TOP-140
-
Brand Name:
-
TUOERPU
-
Certificate::
-
iso 9001 :2008 , CE approved actuator
-
Ball Rotation Angle::
-
90°
-
Color:
-
Blue ,Orange etc
-
Torque:
-
50~2000N.m
-
Time:
-
4~50s
-
Voltage:
-
12~440V
-
Protection Level:
-
IP65 (Optional :IP67/IP68)
-
Input/output signal:
-
4-20mA 0-10VDC
Explosion-proof type
Characteristic
|
Model NO.
|
L(mm)
|
W(mm)
|
H(mm)
|
|
TOP-105
|
146
|
144
|
127
|
|
TOP-110
|
190
|
167
|
155
|
|
TOP-116
|
|
|
|
|
TOP-120
|
235
|
185
|
175
|
|
TOP-140
|
|
|
|
|
TOP-160
|
|
|
|
|
TOP-1100
|
283
|
185
|
175
|
|
TOP-1200
|
|
|
|
FAQ:
1.Is sample order acceptable ?
Of course ,we accept .
2.How to place the order ?
You can send us email or inquiry on Alibaba directly .
3.How many days for delivery ?
For standrd products , we can send out 7 days after payment .
4 .How do make the payment ?
We accept Bank T/T ,L/C.
5.How will make the shippment ?
A.By Sea Shippment ,By Air ,Express Service
