Quick Details
-
Type:
-
Air Source Heat Pump
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Gree
-
After-sales Service Provided::
-
Free spare parts
-
Warranty::
-
5 Year
-
Sound Pressure Level::
-
49/50dB(A)
-
OEM Service::
-
Accept
-
Water Tank Volume::
-
150/200/270L
-
Power supply::
-
220V~240V/50Hz/1ph
-
Name::
-
All in One Heat Pump Water Heater
-
Refrigerant::
-
R134A/R32/R410a
-
Outlet Water Temperature::
-
35°C~70°C
-
Type::
-
Air Source Water Heater
Quick Details
-
Warranty:
-
5 years
-
Application:
-
Car, RV, Outdoor, Hotel, Garage, Commercial, Household
-
Power Source:
-
Electric
-
Type:
-
Air Source Heat Pump
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Gree
-
After-sales Service Provided::
-
Free spare parts
-
Warranty::
-
5 Year
-
Sound Pressure Level::
-
49/50dB(A)
-
OEM Service::
-
Accept
-
Water Tank Volume::
-
150/200/270L
-
Power supply::
-
220V~240V/50Hz/1ph
-
Name::
-
All in One Heat Pump Water Heater
-
Refrigerant::
-
R134A/R32/R410a
-
Outlet Water Temperature::
-
35°C~70°C
-
Type::
-
Air Source Water Heater
|
Product Specifications - Outdoor Units
|
|
|
|
|
|
|
||||||
|
Model
|
|
|
GRS-CQ8.0
|
GRS-CQ10
|
GRS-CQ12
|
GRS-CQ14
|
||||||
|
Power Supply
|
|
V/Ph/Hz
|
220~240/1/50
|
220~240/1/50
|
220~240/1/50
|
220~240/1/50
|
||||||
|
Capacity |
Cooling
|
kw
|
7.8
|
8.2
|
12.5
|
13.5
|
||||||
|
|
Heating
|
kw
|
8
|
10
|
12
|
14
|
||||||
|
Power Input
|
Cooling
|
kw
|
2
|
2.1
|
3
|
3.4
|
||||||
|
|
Heating
|
kw
|
1.8
|
2.3
|
2.8
|
3.3
|
||||||
|
EER/COP
|
|
W/W
|
4/4.5
|
3.9/4.4
|
4.2/4.3
|
4.0/4.2
|
||||||
|
Refrigerant charge volume
|
|
kg
|
2.3
|
2.3
|
3.6
|
3.6
|
||||||
|
Sanitary water Temperature
|
|
℃
|
40~80
|
40~80
|
40~80
|
40~80
|
||||||
|
Sound Pressure Level
|
cooling
|
dB(A)
|
56
|
56
|
58
|
58
|
||||||
|
|
heating
|
dB(A)
|
56
|
56
|
58
|
58
|
||||||
|
Connecting pipe
|
Gas
|
mm
|
φ15.9
|
φ15.9
|
φ15.9
|
φ15.9
|
||||||
|
|
Liquid
|
mm
|
φ9.52
|
φ9.52
|
φ9.52
|
φ9.52
|
||||||
|
Dimensions (W×D×H)
|
Outline
|
mm
|
980x427x788
|
980x427x788
|
900x412x1345
|
900x412x1345
|
||||||
|
|
Packaged
|
mm
|
1097x478x967
|
1097x478x967
|
998x458x1515
|
998x458x1515
|
||||||
|
Net weight/Gross weight
|
|
kg
|
80/89
|
80/89
|
107/117
|
107/117
|
||||||
|
Loading quantity
|
40’GP
|
set
|
96
|
96
|
50
|
50
|
||||||
|
|
40’HQ
|
set
|
96
|
96
|
50
|
50
|
||||||
|
Product Specifications - Indoor Unit
|
|
|
|
|
|
|
||||||
|
Model
|
|
|
GRS-CQ8.0
|
GRS-CQ10
|
GRS-CQ12
|
GRS-CQ14
|
||||||
|
Nominal input
|
|
w
|
6140
|
6140
|
6140
|
6140
|
||||||
|
Leaving water temperature |
Cooling1
|
℃
|
18
|
18
|
18
|
18
|
||||||
|
|
Cooling2
|
℃
|
7
|
7
|
7
|
7
|
||||||
|
|
Heating3
|
℃
|
35
|
35
|
35
|
35
|
||||||
|
|
Heating4
|
℃
|
45
|
45
|
45
|
45
|
||||||
|
Pump |
Type
|
|
Water-cooled
|
Water-cooled
|
Water-cooled
|
Water-cooled
|
||||||
|
|
Nr. of speed
|
|
Variable-speed
|
Variable-speed
|
Variable-speed
|
Variable-speed
|
||||||
|
|
Power input
|
W
|
105
|
105
|
105
|
105
|
||||||
|
|
Water Flow Limit
|
LPM |
12 |
|
|
|
||||||
|
Electric Heater |
Operation
|
-
|
-
|
-
|
-
|
-
|
||||||
|
|
Steps
|
|
2
|
2
|
1
|
1
|
||||||
|
|
Capacity
|
kW
|
3
|
3
|
3
|
3
|
||||||
|
|
Combination
|
kW
|
3+3
|
3+3
|
6
|
6
|
||||||
|
|
Power input
|
Ph/V/Hz
|
230/1/50
|
230/1/50
|
230/1/50
|
230/1/50
|
||||||
|
Sound pressure level
|
|
dB(A)
|
31
|
31
|
31
|
31
|
||||||
|
Dimensions (W×D×H)
|
Outline
|
mm
|
981×500×324
|
981×500×324
|
981×500×324
|
981×500×324
|
||||||
|
|
Packaged
|
mm
|
1043×608×395
|
1043×608×395
|
1043×608×395
|
1043×608×395
|
||||||
|
Net weight/Gross weight
|
|
kg
|
56/65
|
56/65
|
58/67
|
58/67
|
||||||
|
Loading quantity
|
40’GP
|
set
|
205
|
205
|
205
|
205
|
||||||
|
|
40’HQ
|
set
|
246
|
246
|
246
|
246
|
||||||
