- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Lingtai
-
RF output power:
-
33dBm
-
Modulation:
-
DSB-ASK
-
Antenna:
-
4 TNC antenna interface
-
Reading distance:
-
0-10 meters
-
Wirting distance:
-
0-5 meters
-
Power supply:
-
DC 24V/2.5A (DC 9V~30V,60W) or POE(IEEE 802.3 af/at/bt)
-
Support:
-
Support secondary development
-
Size:
-
188.5mm*110mm*37.5mm
-
Wight:
-
0.72Kg
Quick Details
-
Frequency:
-
920MHz~925MHz
-
Protocol:
-
EPC Class 1 Gen2,ISO18000-6C
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
Lingtai
-
RF output power:
-
33dBm
-
Modulation:
-
DSB-ASK
-
Antenna:
-
4 TNC antenna interface
-
Reading distance:
-
0-10 meters
-
Wirting distance:
-
0-5 meters
-
Power supply:
-
DC 24V/2.5A (DC 9V~30V,60W) or POE(IEEE 802.3 af/at/bt)
-
Support:
-
Support secondary development
-
Size:
-
188.5mm*110mm*37.5mm
-
Wight:
-
0.72Kg
Product Description
Features
|
Physical parameters
|
|
|
|
Size
|
188.5mm×110mm×37.5mm
|
|
|
Weight
|
0.72kg
|
|
|
Color
|
Sliver
|
|
|
UHF technical parameter
|
|
|
|
Air protocol
|
920MHz ~ 925MHz, ETSI, 865 ~ 868MHz, FCC, 902 ~ 928MHz (default), full channel
|
|
|
Features
|
Support dense read and write, multi -label recognition, label data filtering, support RSSI, perceive signal strength
|
|
|
working frequency
|
920MHz～925MHz 、ETSI：865～868MHz（optional）
GB：840～845MHz（optional） 、FCC：902～928MHz（optional） |
|
|
RF output power
|
33dBm
|
|
|
Output power adjustment
|
1 db step walking
|
|
|
Antenna specification
|
4 TNC antenna interface
|
|
|
Consecutive label distance (Reading EPC code)
|
0-10 meters (related to the performance of the tag chip), using a 9dBi antenna, with a read success rate of greater than 95% in a
non-interfering environment |
|
|
Continuous writing tag distance (Write EPC code)
|
0-5 meters (related to the performance of the tag chip), using a 9dBi antenna, with a read success rate of greater than 90% in a
non-interfering environment |
|
|
External communication interface
|
TCP/IP, RS232, optional wifi, BT, 4G and other communication modes
|
|
|
working environment
|
|
|
|
Operating Voltage
|
DC 12V/2A (DC 9V～30V，24W) or POE(IEEE 802.3 af/at/bt)
|
|
|
Operating temperature
|
-20℃～+70℃
|
|
|
Storage temperature
|
-40℃～+85℃
|
|
|
Working humidity
|
10 % ～ 95 % Rh without condensation
|
|
W
hy choose Lingta
i
C
ompany Information
Chengdu Kehong Lingtai Automatic Identification Technology Co., Ltd. has developed into a leading global provider of RFID technology solutions since its establishment in 2006.It is an international high-tech enterprise integrating R&D, production, sales and service.We focus on the research and development of full-band series of intelligent devices, and are committed to providing customers
with comprehensive and systematic product solutions, and becoming a core value provider in
the field of internet of Things. Our products have been widely used in many fields around the world, such as power, tobacco, medical care, energy, transportation and logistics, providing efficient and reliable RFlD readers and modules for customers in various industries. As a bench marking enterprise in the RFlD industry, we have passed ISO9001 quality system certification and have multiple independent intellectual property rights.
P
roduct Process
R
&D Equipment
D
ebug / Production
O
ur certification
F
AQ
1. Are you manufacturer?
Yes, we are manufacturers. We have been in RFID industrial for 17+ years. We can provide OEM / ODM customized service according to our customers' various application and demands.
2.What warranty for the products?
According to our warranty policy, we will provide 12 months warranty time from the shipment date for our all products . As for the mass order, we will provide certain proportion spare parts or RMA machine for local service.
3. Can we get the free sample?
Sorry, generally we would not provide the free sample. If the customer confirm the specification and price, they can order the sample firstly for the testing and evaluation. When they place the mass order, we can return the sample cost to the customers.
4. Do you accept Paypal?
Yes, we accept paypal. Besides, we accept T/T, L/C, Secure payment (Escrow Service from Alibaba) and so on.
5. What's the delivery time?
Generally, sample can be shipped in 2-3 working days after payment. For quantity, the leading time will be 1-4 weeks depend on quantity.
6.Which way to deliver the goods?
By Express: DHL UPS TNT FEDEX or ARAMEX EMS E-packing.
By Sea: Inform us the Sea Port to check which ship line.
By Air: Inform us the Airport to check which flight.
7.What the after sale service?
a. Our all products will provide 12 months warranty;
b. Enough stock spare parts for guarantee;
c. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
d. As for the returned failure products, we will fix it and return to the customers in one week after we received it;
