2. It is made of food grade silica gel
3. Customized services are available
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
XJ-GJG
-
Type:
-
Silicone Rubber Soft Tube
-
Material:
-
Silicone
-
Application:
-
Industrial Water
-
Color:
-
Customized Color
-
Product name:
-
Silicone Rubber Tube
-
Name:
-
Food Grade Hose
-
Size:
-
10*14
-
Feature:
-
High Temperature Resistance
-
Certification:
-
Rosh
-
Working temperature:
-
-50℃-200℃
Quick Details
-
Processing Service:
-
Moulding, Cutting
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
xingjia
-
Model Number:
-
XJ-GJG
-
Type:
-
Silicone Rubber Soft Tube
-
Material:
-
Silicone
-
Application:
-
Industrial Water
-
Color:
-
Customized Color
-
Product name:
-
Silicone Rubber Tube
-
Name:
-
Food Grade Hose
-
Size:
-
10*14
-
Feature:
-
High Temperature Resistance
-
Certification:
-
Rosh
-
Working temperature:
-
-50℃-200℃
Our Advantages
advantage:
1. High temperature resistance 200 ℃, low temperature - 50 ℃
Product application
Performance characteristics
1. Non toxic, odorless, high transparency and no yellowing;
2. It is soft, elastic, resistant to kink and deformation;
3. No cracking, long service life, cold and high temperature resistance;
4. It has higher tear strength and superior electrical performance;
Dimension specification
|
Inter diameter(MM)
|
Wall thickness(MM)
|
|
0.5-120MM
|
0.5-8MM
|
Specifications can be customized, inner diameter 0.5 mm-65 mm, wall thickness 0.3-8 mm.
|
Item
|
parameter
|
|
Tensile strengthMPa(Kg/cm2)
|
≧6.9
|
|
Elongation
|
≧300%
|
|
Tear strength kN/m(kg f/cm)
|
≧24.5
|
|
Physical resistivity Ω·m(Ω·cm)
|
≧2×10
14
|
|
Dielectric strength KV/mm
|
≧25
|
|
Dielectric constant（ε）50Hz
|
≧3.2
|
|
Dielectric loss tangent 50Hz
|
0.001
|
|
Use temperature range℃
|
-50～+200
|
|
Asing condition 200°C
|
4h No cracking
|
|
Breakdown strength
|
20kv/mm
|
|
Ozone resistance
|
No crack
|
Details Images
Hardness:
40 ~ 80 degrees;
Common colors:
transparent, white, black, red, green, blue, gray
Food grade silica gel is made of high quality silica gel (a brand new imported food grade silica gel material) through scientific formula and advanced technology.
The product has the characteristics of softness, high temperature resistance and stability.
In today's healthy diet, food grade silicone has gradually replaced food grade plastic.
