Quick Details
-
Type:
-
Air Source Heat Pump
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Haier or OEM
-
Model Number:
-
HPWH-M7
-
Product Name:
-
Full Inverter All in One Air to Water Heat Pump Water Heater
-
Keyword:
-
Heat Pump Water Heaters
-
Function:
-
House Heating Cooling Hot Water
-
Refrigerant:
-
R290
-
Corrosion protection:
-
Magnesium rod
-
Compressor:
-
Full Inverter Compressor
-
Tank volume:
-
185L/194L/240L/250L
-
Power supply:
-
220~240v/50hz
-
Max Hot Water Temperature:
-
65C
-
Water Proof Grade:
-
Ipx4
Quick Details
-
Warranty:
-
3 years
-
Application:
-
Car, RV, Outdoor, Hotel, Garage, Commercial, Household
-
Power Source:
-
Electric
-
Type:
-
Air Source Heat Pump
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Haier or OEM
-
Model Number:
-
HPWH-M7
-
Product Name:
-
Full Inverter All in One Air to Water Heat Pump Water Heater
-
Keyword:
-
Heat Pump Water Heaters
-
Function:
-
House Heating Cooling Hot Water
-
Refrigerant:
-
R290
-
Corrosion protection:
-
Magnesium rod
-
Compressor:
-
Full Inverter Compressor
-
Tank volume:
-
185L/194L/240L/250L
-
Power supply:
-
220~240v/50hz
-
Max Hot Water Temperature:
-
65C
-
Water Proof Grade:
-
Ipx4
TECHNICAL PARAMETERS
|
Model
|
HP200M7
|
HP200M7C
|
HP250M7
|
HP250M7C
|
||||
|
Tank
|
|
|
|
|
||||
|
Total cylinder capacity(L)
|
194
|
185
|
250
|
240
|
||||
|
Tank Max pressure(kPa)
|
700
|
700
|
700
|
700
|
||||
|
Rated voltage/frequency(V/Hz)
|
220-240V/50Hz
|
220-240V/50Hz
|
220-240V/50Hz
|
Magnesium rod
|
||||
|
Corrosion protection
|
Magnesium rod
|
Magnesium rod
|
Magnesium rod
|
Magnesium rod
|
||||
|
Insulation protection rating
|
IPX4
|
IPX4
|
IPX4
|
IPX4
|
||||
|
Performance
|
|
|
|
|
||||
|
COP@7°C(EN16147)
|
3.2
|
3.2
|
3.23
|
3.21
|
||||
|
COP@14°C
|
3.6
|
3.6
|
3.6
|
3.6
|
||||
|
Power input by electric backup(W)
|
1500
|
1500
|
1500
|
1500
|
||||
|
Rated power input by heat pump(W)
|
320
|
320
|
320
|
320
|
||||
|
Maximum power input by heat pump(W)
|
535
|
M
|
L
|
|
||||
|
Maximum power input(W)
|
2035
|
20
|
21
|
|
||||
|
Heating water capacity(L/h)
|
24
|
137
|
193
|
|
||||
|
Heating up time(10°C/55°C)@7°C(h)
|
7
|
6.8
|
10.5
|
10.3
|
||||
|
Default temperature setting(°C)
|
65
|
55
|
55
|
|
||||
|
Temperature setting range with heater(°C)
|
35-75
|
35-75
|
35-75
|
|
||||
|
Maximum temperature output for the heat pump only(°C)
|
65
|
35-65
|
35-65
|
|
||||
|
Max working pressure of refrigerant(MPa)
|
1.0/3.3
|
R134A/0.45
|
R134A/0.46
|
|
||||
|
Refrigerant type/weight(kg)
|
R290/0.15
|
0
|
0
|
|
||||
|
Sound power level *@1 metre(dB(A))
|
50
|
1430
|
1430
|
|
||||
|
V40(L)
|
239
|
228
|
307
|
295
|
||||
|
Ambient temperature of heat pump(°C)
|
-7-45
|
-7-45-7-45°C
|
-7-45°C
|
|
||||
|
Dmensions and connections
|
|
|
|
|
||||
|
Water inlet and outlet connection
|
Rp 3/4
|
G1/2"M
|
G1/2"M
|
|
||||
|
TPR valve connection
|
Rp 3/4
|
G1/2"M
|
G1/2"M
|
|
||||
|
Drain & water inlet connection
|
Rp 3/4
|
G1/2"M
|
G1/2"M
|
|
||||
|
Product dimensions(mm)
|
600*620*1694
|
600*620*1694
|
600*620*1989
|
600*620*1989
|
||||
|
Packing dimension with pallet(mm)
|
736*695*1940
|
736*695*1940
|
736*695*2250
|
736*695*2250
|
||||
|
Net/gross weight(kg)
|
86/109
|
96/119
|
98/121
|
107/131
|
||||
|
Filled weight of the appliance(kg)
|
281
|
282
|
347
|
349
|
||||
|
*THE COP was measured under test conditions with an ambient air temperature of 20°C/15°C (Dry Bulb/Wet Bulb) and heating of the water from 15°C to 55°C during water heater operation.
*The noise level was measured at 1 m from the water heater during a Noise Test conducted to Standard GB/T 23137 in a hemi-anechoic chamber with in a laboratory.
|
|
|
|
|
||||
