Quick Details
-
Brand Name:
-
Sunrise
-
Fork Length:
-
1070mm
-
Fork Width:
-
100mm
-
Overall Dimensions:
-
3608x1145x2090mm
-
Weight (KG):
-
3710 kg
-
Type:
-
Counter Balance Internal Combustion Forklift
-
Engine:
-
Japan Nissan K21/K25
-
Weight:
-
3710kgs
-
Color:
-
Yellow Red Orange Yellow
-
Loading Capacity:
-
2500kg
-
MOQ:
-
1 UNIT
-
Mast:
-
2 Stage/3 Stage
-
Tire:
-
Pneumatic Tire
-
Load Center:
-
600 Mm
Quick Details
-
Min. Lifting Height:
-
110mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sunrise
-
Fork Length:
-
1070mm
-
Fork Width:
-
100mm
-
Overall Dimensions:
-
3608x1145x2090mm
-
Weight (KG):
-
3710 kg
-
Type:
-
Counter Balance Internal Combustion Forklift
-
Engine:
-
Japan Nissan K21/K25
-
Weight:
-
3710kgs
-
Color:
-
Yellow Red Orange Yellow
-
Loading Capacity:
-
2500kg
-
MOQ:
-
1 UNIT
-
Mast:
-
2 Stage/3 Stage
-
Tire:
-
Pneumatic Tire
-
Load Center:
-
600 Mm
CE Certification New Design 1.5ton 2ton 2.5ton 3ton LPG Forklift Gasoline Forklift Truck
Product Description
| MAIN SPECIFICATIONS AND TECHNICAL DATA FOR 2.5T FORKLIFT TRUCK | ||
| Truck model | CPQD25FB/CPYD25FB | |
| Rated capacity / load center | Kg/mm | 2500/500 |
| Maxlift height | mm/kg | 3000 |
| Maxlift speed(loaded/unloaded) | mm/s | 550\580 |
| Inclination of mast forward /backward | deg | 6\12 |
| Trael speed forward / backward | km/h | 18/20 |
| Min.outside turning radius | mm | 2245 |
| Max.permissible gradient | % | 20% |
| Overall length (inclfork) | mm | 3608 |
| Overall width | mm | 1145 |
| Overall height | mm | 2090 |
| Overhead height | mm | 2070 |
| Wheel base | mm | 1600 |
| Track front/ rear | mm | 970/980 |
| Min.ground clearance | mm | 115 |
| Fork length | mm | 1070 |
| Service weight | kg | 3710 |
| Engine | JAPAN NISSAN | |
| Model | K21/K25 | |
| Rated output | kw/rpm | 37.4/2300 |
| CYL No./Displacement | unit/l | 4/2.488 |
| Max.torque | Nm/rpm | 176.5/1600 |
| Front Tyes | 7.00-12-12PR | |
| Rear Tyes | 6.00-9-10PR | |
| Transmissionform | HYDRAULIC | |
| Fuel | Gasoline/LPG | |
