1. Full DC stepless(1Hz) inverter technology: high efficiency and more energy-saving ;
2. High-Efficiency A+++ Energy Level , higher water temp. outlet up to 75 ℃ ；
3. EVI technology: stable Running at -30℃ Ambient Temperature ;
4. 38dB low frequency silent cruise technology: ultra-silence
5. Low noise levelSpecial design of air system which can work in super quiet condition with low noise level of 39db.
6. Famous Brand Water Pump Built-In .
- Product Details
- {{item.text}}
Quick Details
-
Type:
-
Air Source Heat Pump
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM/MICOE
-
Model Number:
-
MMHP-B1/B2
-
Private Mode:
-
Yes
-
Certification:
-
CE ERP ROHS
-
Voltage:
-
220V/380V 50HZ/60HZ
-
Refrigerant:
-
R32 R290
-
Storage:
-
Instant
-
App-controlled:
-
Yes
Quick Details
-
Warranty:
-
3 years
-
Application:
-
Outdoor, Hotel, Garage, Commercial, Household
-
Power Source:
-
Battery, Electric, Solar
-
Type:
-
Air Source Heat Pump
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM/MICOE
-
Model Number:
-
MMHP-B1/B2
-
Private Mode:
-
Yes
-
Certification:
-
CE ERP ROHS
-
Voltage:
-
220V/380V 50HZ/60HZ
-
Refrigerant:
-
R32 R290
-
Storage:
-
Instant
-
App-controlled:
-
Yes
Product Description
MICOE has developed the R290 air-to-water heat pump - Three in one Series, which reduces carbon emissions to the environment and curbs global warming. This refrigerant contributes to the reduction of carbon emissions and helps achieve the global goal of carbon neutrality by having many advantages such as low carbon emissions and high efficiency.
Product Description.
Product Paramenters
|
Model:
|
|
Unit
|
R290- 9
|
R290-15-1
|
R290-15-3
|
R290-22-1
|
R290-22-3
|
|||||
|
Nominal Heating( Max)
(A7/6℃, W30/35℃)
|
Heating
Capacity
|
kW
|
2.92-9.10
|
4.30-15.2
|
|
7.24-21.90
|
|
|||||
|
|
Power Input
|
kW
|
0.61-2.11
|
0.87-3.73
|
|
1.50-5.88
|
|
|||||
|
|
Current Input
|
kW
|
2.80-9.25
|
4.02-16.38
|
1.78-6.04
|
6.86-30.25
|
2.82-9.16
|
|||||
|
|
COP
|
W/W
|
4.31-5.66
|
4.07-5.57
|
|
6.36-19.45
|
|
|||||
|
Nominal Heating( Max)
(A7/6℃, W30/35℃)
|
Heating Capacity
|
kW
|
2.99-8.16
|
4.25-14.55
|
|
6.36-19.45
|
|
|||||
|
|
Power Input
|
kW
|
1.03-2.92
|
1.45-4.28
|
|
2.15-6.85
|
|
|||||
|
|
Current Input
|
kW
|
4.57-12.79
|
6.71-18.80
|
2.84-6.78
|
9.84-30.12
|
3.71-10.60
|
|||||
|
|
COP
|
W/W
|
2.79-3.46
|
2.83-3.45
|
|
2.84-3.57
|
|
|||||
|
(A7/6℃, W30/35℃) |
Heating Capacity
|
kW
|
1.38-5.70
|
3.65-11.04
|
|
4.55-17.20
|
|
|||||
|
|
Power Input
|
kW
|
0.67-2.44
|
1.12-3.97
|
|
1.85-7.31
|
|
|||||
|
|
Current Input
|
kW
|
3.06-10.27
|
5.18-17.44
|
1.97-6.30
|
8.47-32.1
|
2.99-11.26
|
|||||
|
|
COP
|
W/W
|
2.47-3.35
|
2.45-3.30
|
2.45-3.30
|
2.42-3.27
|
2.42-3.27
|
|||||
|
ERP Level( Outlet water temp. at 35℃)
|
|
/
|
A+++
|
A+++
|
A+++
|
A+++
|
A+++
|
|||||
|
ERP Level( Outlet water temp. at 55℃)
|
|
/
|
A++
|
A++
|
A++
|
A++
|
A++
|
|||||
|
SCOP(Outlet water temp. at 35℃)
|
|
/
|
4.83
|
4.77
|
4.74
|
4.81
|
4.79
|
|||||
|
SCOP(Outlet water temp. at 35℃)
|
|
/
|
3.71
|
3.77
|
3.70
|
3.72
|
3.71
|
|||||
|
Rated input power
|
|
kW
|
3.50
|
5.40
|
5.85
|
7.50
|
10.50
|
|||||
|
Rated input current
|
|
A
|
15.00
|
25.00
|
10.00
|
35.00
|
17.00
|
|||||
|
Refrigerant Type/ Charge/ GWP
|
|
/
|
R290/0.55/3
|
R290/1.05/3
|
|
R290/1.4/3
|
|
|||||
|
Rated water flow
|
|
m3/h
|
1.00
|
2.06
|
|
3.10
|
|
|||||
|
Fan quantity
|
|
/
|
1
|
|
|
2
|
|
|||||
|
Fan motor type
|
|
/
|
DC inverter
|
|
|
|
|
|||||
