- Product Details
- {{item.text}}
Quick Details
-
Size:
-
13000mm*2550mm*4000mm
-
Place of Origin:
-
Shandong, China
-
Overall Dimension:
-
13000mm*2550mm*4000mm
-
Tare Weight:
-
9400kg
-
Tires:
-
315/80R22.5 13units
-
Leaf spring:
-
Standard for plate spring
-
Accessories:
-
One standard tool box,A spare tire frame.
-
floor:
-
floor: Patterned plate 3mm
-
Post of standing:
-
Pull station column 12, height 2000MM, 100*100 square tube &=5MM
-
Ladder:
-
Front cover with tarpaulin frame - ladder
-
Carton board:
-
Box board 600+ gap 150+ flower bar 450+ gap 150+ flower bar 450
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
25001-30000 kg
-
Brand Name:
-
huahang
-
Size:
-
13000mm*2550mm*4000mm
-
Place of Origin:
-
Shandong, China
-
Overall Dimension:
-
13000mm*2550mm*4000mm
-
Tare Weight:
-
9400kg
-
Tires:
-
315/80R22.5 13units
-
Leaf spring:
-
Standard for plate spring
-
Accessories:
-
One standard tool box,A spare tire frame.
-
floor:
-
floor: Patterned plate 3mm
-
Post of standing:
-
Pull station column 12, height 2000MM, 100*100 square tube &=5MM
-
Ladder:
-
Front cover with tarpaulin frame - ladder
-
Carton board:
-
Box board 600+ gap 150+ flower bar 450+ gap 150+ flower bar 450
Product Description
3 Axles 60 Ton 50 Ton Side Tipping Dump Truck Semi Trailer Side Tipper Dump Trailer Side Dump Semi-trailer for sale
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Product Paramenters
|
Overall Dimension
|
|
13000mm*2550mm*1800mm
|
|
|
||||
|
Tare Weight
|
|
9500kg
|
Pay Load
|
60ton
|
||||
|
Tires
|
|
315/80R22.5 13units
|
|
|
||||
|
Brakes
|
|
WABCO-ABS
|
|
|
||||
|
King Pin
|
|
JOST 50# (2'') or 90#(3.5''); Type: welded or assembled
|
|
|
||||
|
axle
|
3 Axles FUWA axle, load capacity 13T
|
|
|
|
||||
|
girder
|
Top 14MM, middle 8MM, bottom 16MM，Steel channel
|
|
|
|
||||
|
outrigger
|
JOST 28ton Single action
|
|
|
|
||||
|
Leaf spring
|
10*16*90。
|
|
|
|
||||
|
Accessories
|
One standard tool box，A spare tire frame。
|
|
|
|
||||
|
floor
|
Patterned plate 3mm，Side panels 2mm corrugated panels
|
|
|
|
||||
|
append
|
10x10 square tube
|
|
|
|
||||
|
Oil cylinder
|
130#6+1
|
|
|
|
||||
|
Others
|
Install 8 sets of locks
|
|
|
|
||||
|
All the parts can be customized as required.
|
|
|
|
|
||||
Recommend Products
Our Advantages
We have rich export experience! Our products are exported to many countries in Africa, Southeast Asia, and South America, and our customers are also very satisfied with our products and services. We have the ability to solve any problems you may encounter. We will provide you with the most suitable trailer configuration, the most favorable price, and the best quality. Looking forward to your inquiry!!
