Quick Details
-
Brand Name:
-
CWX
-
Standard or Nonstandard:
-
Standard
-
size:
-
/4",1/2",3/4",1",1 1/4" ,8mm,10mm,15mm,20mm,25mm,32mm
-
material:
-
stainless steel (304, 316), brass
-
work voltage:
-
3-6VDC,12VDC,24VDC,110VAC,220VAC
-
using life:
-
100,000 times
-
Working pressure:
-
1.0Mpa/10bar/150psi
-
Torque output:
-
1.5NM-6NM
-
Control mode:
-
2,3,5 wires(CR10-CR06)
-
End::
-
BSP(British Standard)&NPT(ASSI) Thread
-
Special function:
-
position indicator;quick open,signal feedback,manual override
Quick Details
-
Port Size:
-
1/2'', 3/4'', 1''
-
Place of Origin:
-
Tianjin, China
-
Model Number:
-
CWX-15N
-
Brand Name:
-
CWX
-
Standard or Nonstandard:
-
Standard
-
size:
-
/4",1/2",3/4",1",1 1/4" ,8mm,10mm,15mm,20mm,25mm,32mm
-
material:
-
stainless steel (304, 316), brass
-
work voltage:
-
3-6VDC,12VDC,24VDC,110VAC,220VAC
-
using life:
-
100,000 times
-
Working pressure:
-
1.0Mpa/10bar/150psi
-
Torque output:
-
1.5NM-6NM
-
Control mode:
-
2,3,5 wires(CR10-CR06)
-
End::
-
BSP(British Standard)&NPT(ASSI) Thread
-
Special function:
-
position indicator;quick open,signal feedback,manual override
1, Metal gearbox and POM gear design, low noise, perform reliably .
2, Long service life: more than 100000 circles .
3, electric limit and machinery limit design, located accurately, avoid gear run continuously.
4, Mufti-angle assembling, easy to install .
5, Float ball structure, no leakage,especially suitable for heavy pollution conditions.
1.Heat energy meters, fire work, save water system .
2.Auto control system, industrial mini auto control equipment .
3.Water saving equipment, drinking water equipment .
4.Air-conditioning fan coin(HVAC) .
| Product Model | Rated Voltage | Working current | Output Torque | Opening time | Caliber adapter |
| CWX-15Q |
DC3-6V
DC12V AC/DC9-24V AC220V AC85-265V |
Max100mA (CR04 except Max150mA) |
Max1.5NM | <3s | DN8-DN20 |
| CWX-15N | Max2.0NM | <5s | DN8-DN32 | ||
| Working pressure | Power | Medium temperature | Control Mode | IP Grade | Special function |
| Max1.0Mpa | <3W | 0-90℃ | CR01 CR02 CR02+ CR03 CR03A CR04 CR05 | IP65 | CR01 CR02 CR03 CR04(with singal feedback) |
|
Brass
|
Connection-Way | Sizes | d | H | L |
|
Double-internal thread Full-Port |
DN8 | 8 | 46 | 31 | |
| DN15 | 15 | 57 | 38 | ||
| DN20 | 20 | 71 | 45 | ||
| DN25 | 23.5 | 72 | 49 | ||
| Double-internal thread hole shrinkage | DN10 | 8 | 46 | 31 | |
| DN20 | 15 | 66 | 38 | ||
| DN25 | 20 | 72 | 47 | ||
| DN32 | 25 | 86 | 60 | ||
| Vertica Three-Way | DN15 | 12 | 63 | 49 | |
| DN20 | 15 | 66 | 53 | ||
| Iinternal and external Thread | DN15 | 15 | 63 | 38 | |
| DN20 | 15 | 66 | 38 | ||
| DN32 | 20 | 76 | 50 | ||
| Double-internal thread | DN15 | 15 | 68 | 38 | |
| SS304/316 | Double-internal thread | DN8 | 8 | 46 | 31 |
| DN10 | 8 | 46 | 30.5 | ||
| DN15 | 15 | 55 | 38 | ||
| DN20 | 15 | 63 | 39 | ||
| DN20 | 20 | 71 | 45 | ||
| DN25 | 20 | 75 | 47 | ||
| DN25 | 25 | 72 | 49 |
