Quick Details
-
Model Number:
-
High pressure rubber hose
-
Product name:
-
Hydraulic Hose High Pressure Rubber Hose
-
Application:
-
Petroleum Base Hydraulic Fluids
-
Color:
-
Customized Color
-
MOQ:
-
200 Meters
-
Packing:
-
Customized Packing
-
Quality:
-
100% Professional Test
-
OEM:
-
OEM Services Provided
Quick Details
-
Processing Service:
-
Moulding, Cutting
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
shuangcheng
-
Model Number:
-
High pressure rubber hose
-
Product name:
-
Hydraulic Hose High Pressure Rubber Hose
-
Application:
-
Petroleum Base Hydraulic Fluids
-
Color:
-
Customized Color
-
MOQ:
-
200 Meters
-
Packing:
-
Customized Packing
-
Quality:
-
100% Professional Test
-
OEM:
-
OEM Services Provided
Products Description
|
Nominal Diameter
|
|
Inside Diameter (mm)
|
|
Reinforcement Diameter (mm)
|
|
Outside Diameter (mm)
|
|
Working Pressure (max.)
|
Proof Pressure
|
||||
|
Bursting Pressure (min.)
|
Bending Radius (min.)
|
Weight Approx
|
mm
|
inch
|
Min
|
Max
|
Min
|
Max
|
Min
|
||||
|
Max
|
Mpa
|
Mpa
|
Mpa
|
mm
|
Kg/m
|
4.8
|
3/16
|
4.6
|
5.4
|
||||
|
8.9
|
10.1
|
11.9
|
13.5
|
20.7
|
41.4
|
82.7
|
89
|
0.22
|
6.4
|
||||
|
1/4
|
6.2
|
7.0
|
10.6
|
11.7
|
15.1
|
16.7
|
19.0
|
37.9
|
75.8
|
||||
|
102
|
0.31
|
7.9
|
5/16
|
7.7
|
8.5
|
12.1
|
13.3
|
16.7
|
18.3
|
||||
|
17.2
|
34.5
|
68.9
|
114
|
0.38
|
9.5
|
3/8
|
9.3
|
10.1
|
14.5
|
||||
|
15.7
|
19.0
|
20.6
|
15.5
|
31.0
|
62.0
|
127
|
0.45
|
12.7
|
1/2
|
||||
|
12.3
|
13.5
|
17.5
|
19.0
|
22.2
|
23.8
|
13.8
|
27.6
|
55.2
|
178
|
||||
|
0.55
|
15.9
|
5/8
|
15.5
|
16.7
|
20.6
|
22.2
|
25.4
|
27.0
|
10.3
|
||||
|
20.7
|
41.4
|
203
|
0.63
|
19.0
|
3/4
|
18.6
|
19.8
|
24.6
|
26.2
|
||||
|
29.4
|
31.0
|
8.6
|
17.2
|
34.5
|
241
|
0.77
|
22.2
|
7/8
|
21.8
|
||||
|
23.0
|
27.8
|
29.4
|
32.5
|
34.1
|
7.8
|
15.5
|
31.0
|
279
|
0.92
|
||||
|
25.4
|
1
|
25.0
|
26.4
|
32.5
|
34.1
|
36.9
|
39.4
|
6.9
|
13.8
|
||||
The application of the hydraulic hose:
The high pressure hose is mainly used for Mine hydraulic support ,oilfield exploitation ,object construction ,lifting transport metallurgic forging ,mine equipment, ship, injection molding machinery,agricultural machinery , all kinds of machine tools and various industrial sectors.
Machanization and automation in the hydraulic system of conveying with a certain pressure(high pressure) and the temperature of the oil-based(such as mineral oil, soluble oil, hydraulic oil, fuel oil and lubricants) and water-based liquid (such as Emulsion, the oil-water emulsion, water) and liquid transmission used.The maximum working pressure-resistant up to 70-100MPa.
The high pressure hose is mainly used for Mine hydraulic support ,oilfield exploitation ,object construction ,lifting transport metallurgic forging ,mine equipment, ship, injection molding machinery,agricultural machinery , all kinds of machine tools and various industrial sectors.
Machanization and automation in the hydraulic system of conveying with a certain pressure(high pressure) and the temperature of the oil-based(such as mineral oil, soluble oil, hydraulic oil, fuel oil and lubricants) and water-based liquid (such as Emulsion, the oil-water emulsion, water) and liquid transmission used.The maximum working pressure-resistant up to 70-100MPa.
ADVANTAGE OF HIGH PRESSURE HOSE:
1.Selection of synthetic rubber hose with special made, with excellent oil resistance, heat resistance, anti-aging properties.
2,Hose for the high-pressure and superior pulse properties.
3,Hose combination of close,use soft,small defomation under pressure.
1.Selection of synthetic rubber hose with special made, with excellent oil resistance, heat resistance, anti-aging properties.
2,Hose for the high-pressure and superior pulse properties.
3,Hose combination of close,use soft,small defomation under pressure.
Specification
|
item
|
value
|
|
Place of Origin
|
China
|
|
|
Hebei
|
|
Brand Name
|
shuangcheng
|
|
Model Number
|
High pressure rubber hose
|
|
Processing Service
|
Moulding, Cutting
|
|
Product name
|
Hydraulic Hose High Pressure Rubber Hose
|
|
Application
|
Petroleum Base Hydraulic Fluids
|
|
Color
|
Customized Color
|
|
MOQ
|
200 Meters
|
|
Packing
|
Customized Packing
|
|
Quality
|
100% Professional Test
|
|
OEM
|
OEM Services Provided
|
