Quick Details
-
Brand Name:
-
TOP BRAND
-
Model Number:
-
SD60
-
Dimension(Long * Breadth * High):
-
10390*4690*4370mm
-
Rated power:
-
562KW
-
Gradeability:
-
30°
-
Track center distance:
-
2500mm
-
Track shoe width:
-
510/710mm
-
Ground contact length:
-
3840mm
-
Ground voltage:
-
103.2kPa
-
Operating Weight:
-
70630KG
-
Dimension:
-
10390*4690*4370mm
-
Type:
-
Crawler Dozer
Quick Details
-
Machine Weight:
-
70630 KG
-
Dozing Capacity:
-
4.5m³
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
TOP BRAND
-
Model Number:
-
SD60
-
Dimension(Long * Breadth * High):
-
10390*4690*4370mm
-
Rated power:
-
562KW
-
Gradeability:
-
30°
-
Track center distance:
-
2500mm
-
Track shoe width:
-
510/710mm
-
Ground contact length:
-
3840mm
-
Ground voltage:
-
103.2kPa
-
Operating Weight:
-
70630KG
-
Dimension:
-
10390*4690*4370mm
-
Type:
-
Crawler Dozer
Contact
Sales Manager
Yolanda Wang
Maxizm Construction Machinery (Qingdao) Co., Ltd.
Yolanda Wang
Maxizm Construction Machinery (Qingdao) Co., Ltd.
Email:
yolanda@maxizm.com
Wechat/ Mobile/whatsapp: +86 18753855378
Wechat/ Mobile/whatsapp: +86 18753855378
Products Description
1. The bulldozer has a module design for easy and convenient disassembly and repair;
2. Adopting Europe III emission standards, the bulldozer is equipped with an air to air inter-cooling electrical control engine, featuring strong power and low oil consumption;
3.Equipped with a hydrostatic torque converter with locking function, the bulldozer features excellent driving efficiency, which is beneficial in various working conditions;
4. The brake system uses a normally closed type, braking after the engine stops for high safety;
5. The working device uses pilot controls for excellent sensitivity and performance, making it easy to operate
2. Adopting Europe III emission standards, the bulldozer is equipped with an air to air inter-cooling electrical control engine, featuring strong power and low oil consumption;
3.Equipped with a hydrostatic torque converter with locking function, the bulldozer features excellent driving efficiency, which is beneficial in various working conditions;
4. The brake system uses a normally closed type, braking after the engine stops for high safety;
5. The working device uses pilot controls for excellent sensitivity and performance, making it easy to operate
Product Paramenters
|
Parameter
|
SD60-G
|
|
Overall weight(kg)
|
70630
|
|
Rated power/rated speed(kW/rpm)
|
562/2100
|
|
Machine external dimensions(mm)
|
10390×4690×4370
|
|
Track center distance(mm)
|
2500
|
|
Track shoe width(mm)
|
610/710
|
|
Ground contact length(mm)
|
3840
|
|
Fuel tank capacity(L)
|
1150
|
|
Blade type
|
Semi U
|
|
Engine model
|
QSK19
|
