Quick Details
-
Size:
-
1''-6''
-
Inner Rubber:
-
UHMWPE
-
Reinforcement:
-
High Tensile Steel Wire
-
Cover:
-
EPDM Synthetic Rubber
-
Temperature range:
-
-40℃~+120℃(-72℉ to +248℉)
-
Application:
-
Transportation of 98% of all chemicals.solvents and corrosive service
-
Certification:
-
ISO9001:2008 MSHA
-
W.P:
-
10~20 BAR
Quick Details
-
Place of Origin:
-
China
-
Material:
-
EPDM
-
Color:
-
Requirements
-
Size:
-
1''-6''
-
Inner Rubber:
-
UHMWPE
-
Reinforcement:
-
High Tensile Steel Wire
-
Cover:
-
EPDM Synthetic Rubber
-
Temperature range:
-
-40℃~+120℃(-72℉ to +248℉)
-
Application:
-
Transportation of 98% of all chemicals.solvents and corrosive service
-
Certification:
-
ISO9001:2008 MSHA
-
W.P:
-
10~20 BAR
liquids,excellent in handling a wide range of chemicals, petroleum products,
oils and battery processing industry.
Benefits:
Smooth in-liner,especially suitable for conveying of fluid medium.
It offers superior resistance to chemicals,handle 90% of all chemicals liquids
service.
Technical description:
Inner tube: white, smooth, Ultra High Molecular PE(UHMWPE).
Reinforcement: high strength synthetic cord and double helix wire.
Cover: EPDM rubber, resistant to chemical, weathering and ozone.
Temperature range: --40℃ to +100℃
|
Hose Type
|
I.D.
|
|
O.D.
|
Working Pressure
|
|
Bursting Pressure
|
|
Bending Radius
|
Weight
|
|||
|
Dash
|
Inch
|
m m
|
m m
|
Bar
|
PSI
|
Bar
|
PSI
|
m m
|
Kg/M
|
|||
|
-16
|
1''
|
25.4
|
38.0
|
10
|
150
|
30
|
450
|
254.0
|
0.93
|
|||
|
-20
|
1-1/4''
|
31.8
|
45.0
|
10
|
150
|
30
|
450
|
330.0
|
1.25
|
|||
|
-24
|
1-1/2''
|
38.1
|
51.0
|
10
|
150
|
30
|
450
|
381.0
|
1.47
|
|||
|
-32
|
2''
|
50.8
|
64.0
|
10
|
150
|
30
|
450
|
508.0
|
1.92
|
|||
|
-40
|
2-1/2''
|
64.0
|
78.0
|
10
|
150
|
30
|
450
|
635.0
|
2.51
|
|||
|
-48
|
3''
|
76.0
|
89.0
|
10
|
150
|
30
|
450
|
762.0
|
2.90
|
|||
|
-64
|
4''
|
102.0
|
118.0
|
10
|
150
|
30
|
450
|
1010.0
|
3.92
|
|||
|
-80
|
5''
|
125.0
|
145.0
|
10
|
150
|
30
|
450
|
1270.0
|
6.99
|
|||
|
-96
|
6''
|
152.0
|
174.0
|
10
|
150
|
30
|
450
|
1520.0
|
8.99
|
|||
Packing Details :
1. Colorful nylon tape wrapped coils
2. Transparent PVC sea worthy tape wrapped coils
3. Plastic hose reels
4. Wooden hose reels
5. Pallets with hose coils
6. Wooden case with hose coils
Delivery Details :
1. Less than 1000 Meters will delivery within 7days;
2. Less than 5000 Meters will delivery within 10 days.
3. Less than 10000 Meters will delivery within 15 days.
4. One full container will be delivery within 30 days.
