Quick Details
-
Brand Name:
-
Reach Power
-
Model Number:
-
RSPS
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
20kg, 20kg
-
The charging ratio:
-
99%, 99%
-
The discharge rate:
-
96%, 96%
-
Electric Energy:
-
2560 Wh
-
Certification:
-
MSDS,UN38.3,CE,FCC
-
Warranty:
-
5years
-
Chargeable:
-
Yes
Quick Details
-
Storage Type:
-
Dry, dry, cool and ventilation
-
Anode Material:
-
LNO
-
Application:
-
Home Appliances, Golf Carts, Solar Energy Storage Systems
-
Brand Name:
-
Reach Power
-
Model Number:
-
RSPS
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
20kg, 20kg
-
The charging ratio:
-
99%, 99%
-
The discharge rate:
-
96%, 96%
-
Electric Energy:
-
2560 Wh
-
Certification:
-
MSDS,UN38.3,CE,FCC
-
Warranty:
-
5years
-
Chargeable:
-
Yes
|
Item Number
|
12.8V200Ah
|
|
Nominal voltage [V]
|
12.8
|
|
Nominal capacity [Ah]
|
200
|
|
Total energy [KWh]
|
1.28
|
|
Product dimension [W*D*H]
|
530*300*230 mm
|
|
Product weight
|
20±0.5 Kg
|
|
Max. charging current [A]
|
150
|
|
Charge Mode
|
@0.2C(A) to 14.6V ,then @14.6V till charge current<0.05C(A) (CC,CV)
|
|
Charging voltage [V] Max. discharging current [A]
|
14.6 150
|
|
End of discharge voltage [V] Protection class
|
11.2 IP65
|
|
Operating humidity
|
0-95 %RH (No condensing)
|
|
Operating temperature range
|
Charge: 0 ~ +50 °C Discharge: -20 ~ +55 °C
|
|
Storage temperature range
|
-20 ~ +60 °C / -4 ~+140°F
|
|
Communication interface
|
/
|
|
BMS Functions Protection
|
Cell Voltage/Current Balance, Temperature, MOSFETS Over voltage , Low voltage , Over current,
|
|
loiecon Certification
|
Over Temperature, Low Temperature Short circuit UN38.3, CE
|
