Quick Details
-
Brand Name:
-
MWISH
-
Model Number:
-
S-600-12
-
Output Frequency:
-
50/60Hz
-
type:
-
AC-DC
-
Product Name:
-
S-600-12 Switching Power Supply
-
DC Voltage Option:
-
12V
-
Output Current Option:
-
50A
-
Product Size:
-
23.4*12.4*6.4cm
-
Wide Voltage:
-
100~240V AC
-
Variable Voltage:
-
11-15V
-
Eficiency:
-
85%
-
Weight:
-
1.12KG
-
Warranty:
-
5years
-
Key Words:
-
switching power supply
Quick Details
-
Input Voltage:
-
100-240V
-
Output Voltage:
-
12V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
MWISH
-
Model Number:
-
S-600-12
-
Output Frequency:
-
50/60Hz
-
type:
-
AC-DC
-
Product Name:
-
S-600-12 Switching Power Supply
-
DC Voltage Option:
-
12V
-
Output Current Option:
-
50A
-
Product Size:
-
23.4*12.4*6.4cm
-
Wide Voltage:
-
100~240V AC
-
Variable Voltage:
-
11-15V
-
Eficiency:
-
85%
-
Weight:
-
1.12KG
-
Warranty:
-
5years
-
Key Words:
-
switching power supply
Product Description
|
Product Name
|
600W Single Output Switching Power Supply
|
|
Brand Name
|
MWISH
|
|
Model Number
|
S-600-12
|
|
Output Rated Power
|
600W
|
|
Output DC Voltage
|
12V
|
|
Output Rated Current
|
14A
|
|
Output Current Range
|
12V--50A
|
|
Output Ripples And Noise
|
120mVp-p
|
|
Output Voltage Adjustable Range
|
11-15V
|
|
Output Voltage Accuracy
|
±3.0%
|
|
Output Linear Adjustment Rate
|
±0.5%
|
|
Output Load Adjustment Rate
|
±0.5%
|
|
Output Starting Rising Time
|
1500ms,25ms/230VAC at full load
|
|
Output Hold-up Time(Typ.)
|
16ms/230VAC
|
|
Input Voltage Range
|
100～240VAC
|
|
Input Frequency Range
|
47～63Hz
|
|
Input Efficiency(Typ.)
|
85%
|
|
Input AC(Typ.)
|
1A/115VAC
|
|
Input Surge Current(Typ.)
|
Cold Boot 48A/230VAC
|
|
Input Leak Current
|
＜2mA/240VAC
|
|
Overload Protection
|
Rate Output Power 110～140%
|
|
|
Protection Mode:Hiccup mode, automatically recovered after abnormal conditions are removed
|
|
Overvoltage Protection
|
13.8～16.2V
|
|
|
Protection Mode:Turn off the output voltage and restart to restore
|
|
Operating Temperature
|
-25～+70°C
|
|
Operating Humidity
|
20～90%RH,non-condensing
|
|
Operating Temperature,Humidity
|
-40～+80°C,10-95%RH,non-condensing
|
|
Temperature Coefficient
|
±0.03%/°C(0～50°C)
|
|
Vibration Resistance
|
10～500Hz,5G 10mins/period, X、Y 、Z have 60mins separately
|
|
Overvoltage Grade
|
Ⅲ；According to EN61558,EN50178,EN60664-1,EN62477-1；Altitude up to 2000 meters
|
