Quick Details
-
Dial size:
-
63mm-2.5``/costomization
-
Connection Thread:
-
M20x1.5, Pt1/4, Npt1/4
-
Thread Material:
-
Brass
-
Accuracy:
-
1.6%
-
Weight:
-
0.28Kg
-
Installation:
-
Radail/Axial
-
Warranty:
-
1year
-
Color:
-
Black
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Product Name:
-
Vacuum Pressure Gauge
-
Pressure range:
-
-0.1~0Mpa /Customized
-
Dial size:
-
63mm-2.5``/costomization
-
Connection Thread:
-
M20x1.5, Pt1/4, Npt1/4
-
Thread Material:
-
Brass
-
Accuracy:
-
1.6%
-
Weight:
-
0.28Kg
-
Installation:
-
Radail/Axial
-
Warranty:
-
1year
-
Color:
-
Black
To customize the pressure gauge display please click here.
|
Product Name |
Vaccum Pressure Gauge Series |
| Model | Y-63 |
| Diameter | 63mm-2.5`` |
| Scale Range | -0.1~0.5 -0.1~0.9 -0.1~1.5 -0.1~2.4 |
| Thread size | m20x1.5,pt1/4,npt1/4 |
| Filling fluid | NO |
| Net weight of a single table | 0.5kg |
| Anti-Vibration |
V,H,4 |
| Material | Brass |
| Application | Petrol,Mine,Hydraulic industries |
| Accept customization | Yes |
| Precision Grade | 1.6 |
All parameters can be customized according to your requirements.
Fuyang Wanxing Instrument Co.,Ltd.
is located in the southern suburtbs of Fuyang District, Hangzhou in China,
We are one of the national instrumentation production base.
Below products can be provided:
stainless steel pressure gauge,vacuum pressure gauge,
oil filled pressure gauge,digital pressure gauge,
electrical contact pressure gauge,industrial thermometer,
pressure transmitters and so on.
Due to our flexible assembly line,we support 1~15days of delivery.
Q : Wh at is your delivery period?
A: 3~6 0day. ( Some product are stocked in the warehouse )
Q : Where is your factory?
A: We are manufacturer ,and It is located in Hangzhou Zhejiang China.
Q : Do you have after-sell service?
A: Yes ,all our products are of one-year warranty free.
Q : Can you send sample for us?
A: Yes,for cooperation sincerity, we will provide samples for free, but the delivery charges should be at your account.
We can also manufacture according to your sample.
Remarks:
1.Our meters are accurate and we can provide operational instructions and videos for you.
2.Please advise us specs and quantity thus we can quote you the reasonable price.
